Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
Specifications
Brand Name :
Polcd
Model Number :
P032H005
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram
Supply Ability :
40,000 PCS per day
Delivery Time :
40,000 PCS per day
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Number of Pixel :
240x320
Screen Size :
3.2 inch
Display area :
48.60(H)x64.80(V)
Angle of view :
12' o clock
Interface :
MCU 8/16bit SPI 3/4Wire
Driver Ic :
ILI9341V
Description

Description:

3.2'' TFT LCD module is a versatile and reliable display technology that offers high-quality display performance, low power consumption, and durability. Its wide range of applications and customization options make it an ideal choice for a variety of electronic devices.


Parameter:

Model P032H005
Screen Size 3.2 inch
Number of Pixel 240RGB(H)x320(V)
Display area 48.60(H)x64.80(V)mm
Pixel pitch 0.2025(H)x0.2025(V)mm
Pins 40 pins
Outline Dimension 55.04x77.50x2.50mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally White
Viewing Direction(eye) 12 0'CLOCK
Display Color 262K
Luminance(cd/m2) 270 nit
Contrast Ratio 500:1
Interface MCU 8/16bit SPI 3/4Wire
Back-light LED Side-light type
Drive IC ILI9341V
Operation Temperature -20~70℃
Storage Temperature -30~80℃


Features and advantages:

Size and resolution: The 3.2 inch TFT LCD has a diagonal size of 3.2 inches and typically has a resolution of 240x320 pixels, which provides a high-quality display for various applications.

Color display: The TFT LCD can display up to 262,144 colors, providing accurate color representation and making it ideal for displaying images and videos.

Wide viewing angle: The TFT LCD typically has a wide viewing angle, allowing for clear viewing from different angles without distortion or color shift.

Touch screen support: The TFT LCD can support capacitive touch screen input, allowing users to select, slide, and zoom with their fingers.

Low power consumption: TFT LCD technology typically has low power consumption, which is important for devices that run on battery power.

Durability: TFT LCDs are durable and can withstand shock and vibration, making them suitable for use in various applications, including handheld devices, automotive displays, and medical equipment.

Customization: The 3.2 inch TFT LCD can be customized to meet specific application requirements, including different sizes, resolutions, and features.

Polcd 3.2 inch 240x320 pixel size Small TFT Display ILI9488 Driver ic Lcd
