Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Specifications
Brand Name :
Henger
Model Number :
004
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1
Price :
500
Payment Terms :
L/C,D/A,D/P,T/T
Supply Ability :
50 pcs/week
Delivery Time :
15-30 working days
Packaging Details :
nude packing
Product name :
Anchor pendant buoy
Material :
Steel, EVA filling
Size :
Customized Size
Warranty :
12 months
Color :
Customized Color
Logo service :
Customized
Trademark :
Henger
Origin :
China
Design :
Modular Design
Description

Modular Design Large-Diameter Floating Mooring Buoy

Product Description
Steel mooring buoys stand as pivotal anchoring infrastructure within port facilities, meticulously engineered to reliably accommodate vessels across a spectrum of tonnages. Their operational framework is defined by inherent convenience and adaptability: when deployed in anchorage zones, they streamline mooring protocols and adeptly adjust to fluctuations in vessel traffic volumes.
Beyond their core anchoring role, these buoys serve as enablers of critical maritime operations. They offer a stable platform for cargo lightering—facilitating transshipment between vessels to bypass berth limitations—and support on-site vessel maintenance and repair tasks. This capability eliminates the necessity of 占用 precious dry dock resources or disrupting routine port workflows.
In essence, the multifunctionality and operational efficacy of steel mooring buoys render them irreplaceable, underpinning the seamless, agile functioning of modern port operations.

Steel Mooring Buoy Technical Parameter

Model Net Buoyancy D×H (m) Suitable for Ship Tonnage (t)
HESMB 2.0 3 2.0×1.74 <2000
HESMB 2.6 6 2.6×2.27 <5000
HESMB 3.6 19 3.6×2.14 <10000
HESMB 5.0 28.5 5.0×3.4 <12000
HESMB 5.5 31.2 5.5×3.0 <100000
HESMB 6.0 34.2 6.0×3.2 <150000
HESMB 8.0 40.3 8.0×2.46 <250000

Anchor Pendant Buoy


Anchor pendant buoys are available in a wide range of sizes, with choices of suitcase type, modular and non-modular type, custom-made and standard configurations. All are supplied with removable central steel work configured as per to customer’s requirements – typical handing crucifix/pad eye arrangement or a through haws e for use with anchor wire rather than chain.
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy
Modular Large Diameter Floating Mooring Anchor Pendant Buoy

Anchor Pendant Buoy Technical Parameters

Model

 Reserve Buoyancy
(kg)		 Diameter
(mm)		 Float Length
(mm)		 Overall Length
(mm)		 Weight
(kg)

HE-APB1000

 1000 1350 1100 1900 300

HE-APB2000

 2000 1500 1500 2600 500

HE-APB3000

 3000 1850 1500 2600 600

HE-APB4000

 4000 2000 1900 2900 850

HE-APB6000

 6000 2500 2200 3250 1000

HE-APB8000

 8000 2500 2200 3250 1250

HE-APB10000

 10000 3000 2200 3500 1550

HE-APB20000

 20000 3500 3000 4200 2400


*buoy sizes and buoyancy can be customized according to customer design.
