Specifications
Brand Name :
Henger
Model Number :
004
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1
Price :
500
Payment Terms :
L/C,D/A,D/P,T/T
Supply Ability :
50 pcs/week
Delivery Time :
15-30 working days
Packaging Details :
nude packing
Product name :
Anchor pendant buoy
Material :
Steel, EVA filling
Size :
Customized Size
Warranty :
12 months
Color :
Customized Color
Logo service :
Customized
Trademark :
Henger
Origin :
China
Design :
Modular Design
Description

Large Diameter Marine Offshore Steel Floating Mooring Buoy

Product Description
Steel mooring buoys stand as pivotal anchoring infrastructure within port facilities, meticulously engineered to reliably accommodate vessels across a spectrum of tonnages. Their operational framework is defined by inherent convenience and adaptability: when deployed in anchorage zones, they streamline mooring protocols and adeptly adjust to fluctuations in vessel traffic volumes.
Beyond their core anchoring role, these buoys serve as enablers of critical maritime operations. They offer a stable platform for cargo lightering—facilitating transshipment between vessels to bypass berth limitations—and support on-site vessel maintenance and repair tasks. This capability eliminates the necessity of 占用 precious dry dock resources or disrupting routine port workflows.
In essence, the multifunctionality and operational efficacy of steel mooring buoys render them irreplaceable, underpinning the seamless, agile functioning of modern port operations.

Steel Mooring Buoy Technical Parameter


Model Net Buoyancy D×H (m) Suitable for Ship Tonnage (t)
HESMB 2.0 3 2.0×1.74 <2000
HESMB 2.6 6 2.6×2.27 <5000
HESMB 3.6 19 3.6×2.14 <10000
HESMB 5.0 28.5 5.0×3.4 <12000
HESMB 5.5 31.2 5.5×3.0 <100000
HESMB 6.0 34.2 6.0×3.2 <150000
HESMB 8.0 40.3 8.0×2.46 <250000


Anchor Pendant Buoy


Anchor pendant buoys come in an extensive range of sizes, offering options such as suitcase-style, modular, non-modular, custom-made, and standard configurations. All units are equipped with removable central steelwork, which is tailored to meet specific customer requirements—typically featuring either a handling crucifix/pad eye arrangement or a through hawse designed for use with anchor wire instead of chain.
Large Diameter Marine Offshore Steel Floating Mooring Buoy Large Diameter Marine Offshore Steel Floating Mooring Buoy Large Diameter Marine Offshore Steel Floating Mooring Buoy

Anchor Pendant Buoy Technical Parameters


Model


 Reserve Buoyancy
(kg)		 Diameter
(mm)		 Float Length
(mm)		 Overall Length
(mm)		 Weight
(kg)


HE-APB1000


 1000 1350 1100 1900 300


HE-APB2000


 2000 1500 1500 2600 500


HE-APB3000


 3000 1850 1500 2600 600


HE-APB4000


 4000 2000 1900 2900 850


HE-APB6000


 6000 2500 2200 3250 1000


HE-APB8000


 8000 2500 2200 3250 1250


HE-APB10000


 10000 3000 2200 3500 1550


HE-APB20000

 20000 3500 3000 4200 2400


*buoy sizes and buoyancy can be customized according to customer design.
You can contact me at any time if you need it. Thank you for reading.
