Customized Precision Plastic Molds High Accuracy Automotive Plastic Molds For Car Components
Customized Precision Plastic Molds High Accuracy Automotive Plastic Molds For Car Components
Customized Precision Plastic Molds High Accuracy Automotive Plastic Molds For Car Components
Customized Precision Plastic Molds High Accuracy Automotive Plastic Molds For Car Components
Specifications
Brand Name :
MID MOULD
Place of Origin :
Dongguan, China
MOQ :
1 set
Payment Terms :
50% deposit + 30% upon first sample + 20% after sample approval or before final mold shipment
Delivery Time :
25–45 working days (longer for complex tools)
Certification :
ISO9001,FDA,ISO13485
Price :
USD $3,000–$50,000 per set (depending on complexity)
Packaging Details :
Wooden case + anti-rust oil + protective film + packing list
Supply Ability :
20–35 sets per month, depending on structure
Product :
Precision Plastic Molds
Mould life :
250000-300000shots,200~1 M available,300,000shots,000 times
Shaping mode :
Plastic Injection Mould,Plastic injection molding,Compression Mould
Cavity :
Multi Cavity,as per client's requirement
Design software :
CAD,CAD/ProE/UG/SOLIDWORKS,CAD UG Moldflow,Solidworks,PROE
Mould material :
P20/718/738/NAK80/S136,P20/718/2738/H13/S136/NAK80,718,SKD61 etc,H13
Application :
Home Appliance,Industrial,Automotive,various range,Machine
Mould base :
non-Standard plastic injection mould,World standard,European standard,LKM.HASCO,HASCO standard
Surface treatment :
sandblasted,Texture,anodizing black,clear painting,Polishing
Size :
as samples/drawings,customized accepted,Customized Size
Mold runner :
Hot&Cold runner you can choose,Hot runner and code runner
Description
Product Technology

Our automotive precision molds utilize high-strength mold steel and five-axis machining technology to ensure the stability and precision of structural and functional components under complex working conditions. Our manufacturing process strictly adheres to the IATF 16949 automotive quality system, ensuring the molds meet the consistency and durability required for automotive parts.

Process Flow
  1. Component Requirements Analysis and Engineering Standard Confirmation
  2. CAD Design and CAE Strength Simulation
  3. CNC Precision Machining and EDM Micromachining
  4. Mold Assembly and Hot Runner System Installation
  5. Mold Trial and Performance Verification
Product Specifications
Item Parameter Description
Mold TypePrecision injection mold for the automotive industry
Mold MaterialH13, 718H, S136
Cavity Count1–16
Mold Life800,000–1.5 Million Molds
Part Accuracy±0.015mm
Surface TreatmentChrome Plating, Polishing, Nitriding
Applicable MaterialsABS, PA66, GF, PC, PBT
Cooling SystemHigh-efficiency water and oil cooling combination
Hot Runner SystemConfigurable with multi-point needle valve hot runners
Product Cycle55–80 Days
Product Applications
  • Automotive Instrument Panel Housing
  • Interior Function Buttons and Trim Parts
  • Precision Clips and Structural Parts
  • Lighting and Electrical Components
Product Advantages
  • Meets IATF 16949 automotive industry standards
  • ±0.015mm High precision ensures part consistency.
  • Hot runner systems improve production efficiency and reduce scrap.
  • Wear-resistant steel ensures a mold life of up to one million cycles.
  • Withstands thermal loads and mechanical strength under complex operating conditions.
FAQ

Q1: Does the mold meet automotive quality certifications?

A1: Yes. Mold design and manufacturing adhere to the IATF 16949 standard.

Q2: Does it support engineering plastics with glass fiber?

A2: Yes. Common automotive materials such as ABS, PA66, and GF can be processed.

Q3: What is the typical mold life?

A3: Over one million cycles, suitable for long-term mass production.

Q4: Can the mold be configured with a hot runner?

A4: Supports multi-valve hot runners, improving product quality and efficiency.

Q5: Is fast delivery possible?

A5: Typical lead time: 55–80 days. Expedited delivery available

Personalized customization services
  • Customized cavity designs tailored to automotive part precision requirements
  • Hot runner systems and automated demolding solutions available
  • Special treatments such as surface polishing and chrome plating available
  • Customized high-strength cooling circuits to meet the production needs of complex structural parts
