Large-Diameter Hollow-Wall Spiral Wound Pipe Production Line

Large-diameter hollow wall spiral-wound pipes feature a unique“I-shaped ” wall structure.

Why Choose Our Production Line?

1. High-strength structured design with light weight and excellent impact resistance

2.Strong load capacity and long-term performance, resistant to acid, alkali and salt

3.Service life up to 50 years

4.Wide diameter range: 200 mm - 3000 mm

5.Ideal for municipal sewage and drainage projects

6.Perfect replacement for cement and cast iron pipes

7.Low installation cost with easy and fast connection

8.High market demand and strong investment value

Production process of HDPE hollow-wall corrugated pipe extrusion line:

Raw materials→Mixing→Vacuum feeding→Material drying→Single screw extrusion →Calibration→Spray
cooling→ traction→Single screw glue extrusion →Winding and forming→water cooling→cutter→pipe bracket→inspecting &packing.
Large-Diameter Hollow-Wall Corrugated Spiral Wound Pipe Production Line with Unique I-shaped Wall Structure and Automatic Single-Screw Extrusion
Product Parameters
Model Pipe Diameter(mm) Extruder Speed of forming Max. output Installed Power dimension
SKRG-1200 Ø400-Ø1200 SJ-65(50)X30 1-12m/h 320kg/h 230KW 26X18X5
SKRG-1600 Ø800-Ø1600 SJ-80(50)X30 1-6m/h 500kg/h 310KW 27X18X5
SKRG-2200 Ø1000-Ø2200 SJ-90(65)X30 0.5-5m/h 650kg/h 380KW 28X19X5
SKRG-3000 Ø1600-Ø3000 SJ-90(65)X30 0.3-3m/h 800kg/h 390KW 48X26X6

Composition of Equipments
1.1set Single screw extruder with vacuum loader& hopper dryer
2.1set Square tube die head & mould
3.1set Vacuum calibration table
4.1set Water spraying tank
5.1set Hauling machine
6.1set Single screw extruder with vacuum loader & hopper dryer
7.1set Melt adhesive extrusion die head
8.1set Rewinding forming machine
9.1set Cutting machine
10.1set Stacker
11.set PLC

The complete production line includes two parts:

1.The first part is PE Pipe extrusion line to extrude the PE/PP Square Shaped Pipe ( according to customers' requirements ).
Single Screw Extruder
Die Head (mold and mandrill)
Calibrator
Vacuum calibration&cooling Tank
Spray Cooling Tank
Haul-off

2. The second part is Spiral forming line to form and weld the big pipe.
Single Screw Extruder
Die Head
Spiral forming unit
Cutter
Bracket
Detailed Photos

Large-Diameter Hollow-Wall Corrugated Spiral Wound Pipe Production Line with Unique I-shaped Wall Structure and Automatic Single-Screw ExtrusionLarge-Diameter Hollow-Wall Corrugated Spiral Wound Pipe Production Line with Unique I-shaped Wall Structure and Automatic Single-Screw ExtrusionLarge-Diameter Hollow-Wall Corrugated Spiral Wound Pipe Production Line with Unique I-shaped Wall Structure and Automatic Single-Screw Extrusion


Qingdao Huashida Machinery Co., LTD., founded in 2003, is a global developer, manufacturer and solution provider of plastic extrusion equipment. 70% of its customers come from overseas countries such as Europe, America, the Middle East and Southeast Asia.
Welcome to our factory to discuss cooperation!
