Specifications
MOQ :
1
Price :
Inquiry Us
Payment Terms :
T/T
Supply Ability :
200,000+ m² PCB per Month
Layer :
6 Layer
Thickness :
1.60mm+/-10%
Base Material :
Polyimide+FR4 TG150
Copper Thickness :
1OZ
Min. Line Width/Space :
0.13/0.13mm
Sloder Mask :
Green
Surface Treatment :
ENlG + Electroplate Gold
Application :
Medical Devices
Certificate :
UL,IATF16949,ISO&Reach
Description

6 Layers Polyimide 1.60mm Thick Medical Devices Rigid-Flex PCB

♦ What is Rigid-Flex PCB?

Rigid-Flex PCB is a composite structure circuit board that combines a rigid printed circuit board (PCB) and a flexible circuit board (FPC). It is mainly composed of two parts: rigid and flexible. The rigid layer is made of traditional PCB materials (such as FR-4), providing stable electrical performance and mechanical strength; the flexible layer is made of flexible circuit materials such as polyimide or polyester, which has high bending and folding resistance; the two are connected by special adhesives or welding processes.

6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo

♦ Features of Rigid-Flex PCB

  • ​​Flexible design: 3D stereo wiring replaces traditional cables, saves space, and improves integration.
  • ​​Rigid-flexible complementarity: The rigid part provides support, and the flexible part adapts to bending and folding to cope with complex environments.
  • ​​Stable performance: Excellent electrical transmission, good heat dissipation, vibration resistance, corrosion resistance, and high reliability.
  • ​​Efficient wiring: High-density multi-layer design to meet the needs of complex circuits.
  • ​​Widely used: Covering aerospace, medical, automotive, consumer electronics and other fields.
  • ​​Reduce failures: Reduce problems with welding points and cable connections, and improve product stability.
  • ​​Strong impact resistance: Resistant to high stress, suitable for harsh scenarios such as vibration and collision.

♦ Technical Parameters

Item

Spec

Layers

1~64

Board Thickness

0.1mm-10 mm

Material

FR-4, CEM-1/CEM-3, PI, High Tg, Rogers, PTEF, Alu/Cu Base,Ceramic, etc

Max Panel Size

800mm×1200mm

Min Hole Size

0.075mm

Min Line Width/Space

Standard: 3mil(0.075mm) Advance: 2mil

Board Outline Tolerance

士0.10mm

Insulation Layer Thickness

0.075mm--5.00mm

Out Layer Copper Thickness

18um--350um

Drilling Hole (Mechanical)

17um--175um

Finish Hole (Mechanical)

17um--175um

Diameter Tolerance (Mechanical)

0.05mm

Registration (Mechanical)

0.075mm

Aspect Ratio

17:01

Solder Mask Type

LPI

SMT Min. Solder Mask Width

0.075mm

Min. Solder Mask Clearance

0.05mm

Plug Hole Diameter

0.25mm--0.60mm
♦ One-Stop PCBs Solution

6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo
PCB Prototype Felx PCB Rigid-Flex PCB Ceramic PCB
6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo 6 Layer Green Polyimide Fast Turn Rigid Flex PCB TG150 1.6mm For 3D Stereo
Heavy Copper PCB HDI PCB High Frequency PCB High TG PCB

♦ Advantages of DQS Team
  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines

2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%

3. Premium Service:

    • 24H reply your inquiry
    • Perfect after-sales service system
    • From prototype to mass production
