Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
Specifications
Brand Name :
KCO, Kocent Optec Limited
Model Number :
KCO-M/ADSS-G652D-xxFO
Certification :
ISO9001, RoHS
Place of Origin :
Guangdong, China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
Western Union,T/T,L/C
Supply Ability :
10,000km/ month
Delivery Time :
3~5 days after get payment
Packaging Details :
wooden roll, wooden pallet
Material :
PE, LDPE, HDPE
Name :
Outdoor Fiber Optic Cable
Length :
2km~3km each roll
Cable type :
Mini ADSS
Fiber :
Single mode
Cores :
2 cores to 24 cores
Color :
Black
Diameter :
6.5mm
Part number :
KCO-M/ADSS-G652D-xxFO
Description
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
What is ASU Fiber Optic Cable?
  • The ASU Fiber Optic Cable (Aerial Self-Supporting Unit) is engineered for outdoor aerial distribution networks where a lightweight, non-metallic solution is required. As an All-Dielectric cable, the ASU eliminates the need for grounding and is immune to electromagnetic interference, making it the perfect choice for installation alongside power lines on utility poles.
  • The ASU fiber optic cables are designed for operational efficiency, this cable utilizes high-modulus FRP (Fiber Reinforced Plastic) strength members to support spans typically ranging from 80m to 120m, providing a cost-effective alternative to heavy-duty ADSS cables for urban and rural distribution.
  • The ASU fiber optic cable is mini size of ADSS cable, it is small size and light weight, can use to replace small capacity of ADSS cable to save more cost.
ASU Fiber Optical Cable Structurer:
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable

The ASU fiber optic cable structure is optimized to withstand wind load and ice weight without sagging:

  • Central Strength Member (FRP): A solid Fiber Reinforced Plastic rod sits at the center, providing high tensile strength while keeping the cable completely non-metallic.
  • Loose Tube Technology: PBT loose tubes containing the optical fibers (up to 144 cores) are stranded around the central member. These tubes are filled with water-blocking jelly to protect the fibers from moisture.
  • Rip Cord: Included for easy jacket stripping during termination.
  • Outer Sheath (PE): A UV-stabilized, High-Density Polyethylene (HDPE) jacket protects the cable from harsh sunlight, abrasion, and environmental weathering.

Applications

  • Telecommunications: Backbone networks, connecting central offices to distribution points.
  • Access Networks: Last-mile connectivity for homes and businesses.
  • Data Centers & LANs: High-speed connections within campuses or buildings.
  • Industrial & Security: Connecting control systems or surveillance cameras.
ASU Fiber Optic Cable Characteristics
  • Large span lengths with maximum span over 1700 meters
  • Non-metallic material with high insulating properties and lightning-proof performance
  • Special anti-track outer sheath protection with strong anti-electro-corrosion ability
  • Aramid yarn ensures tensile resistance and provides good bullet-proof performance
  • Light weight with small diameter, reducing ice and wind loads as well as tower load
  • Can be installed without shutting off power
Applications
  • Outdoor deployment
  • Suitable for aerial and pipeline laying methods
  • Long distance and local area network communication
Cable Mechanical Characteristics
Item Contents Value
Loose tube Number 1
Outer diameter (mm) 2.1
Thickness 0.3
Materials PBT
Water blocking Tube filling compound
Strength member Materials FRP
Diameter (mm) 2.0 | 2.5
Number 2
Water blocking Material Water blocking yarn
Sheath Material HDPE
Color Black
Rip cord Number 1.2
Cable diameter (mm) Approx 6.5±0.5 | 7.5±0.5
Cable weight (kg/km) Approx 45 | 65
Span (m) 80 | 120
MAT 690 | 980
Fiber Characteristics
Fiber style Unit MM
Condition nm 850/1300
Attenuation dB/km ≤3.0/1.0
Dispersion 1550nm Ps/(nm*km) Dispersion
1625nm Ps/(nm*km)
Bandwidth 850nm MHZ.KM Bandwidth
1300nm MHZ.KM
Zero dispersion wavelength nm ≧ 1295, ≤1320
Zero dispersion slope nm
PMD Maximum Individual Fiber
≤0.11
PMD Design Link Value Ps(nm2*km)
Fibre cutoff wavelength λc nm
Cable cutoff wavelength λcc nm
MFD 1310nm um
1550nm um
Numerical Aperture (NA)
0.200+/-0.015
Step (mean of bidirectional measurement) dB ≤0.10
Irregularities over fiber length and point dB ≤0.10
Fiber Color Coding
Blue Orange Green Brown Grey White Red Black Yellow Violet Pink Aqua
OEM/ODM Service
We offer comprehensive OEM and ODM services. You can display your own brand logo on the cable, packaging bag, label, or any other location as required.
Aerial Overhead Fiber Optic Cable 80M 120M Span USU Optical Fiber Cable 6fo 12fo 24fo / Mini ADSS Cable
Packing
  • Standard export packing
  • Carton box, wooden box, wooden pallet
Shipping
  • International express: UPS, TNT, DHL, etc.
  • International air: CA, AA, EA, etc.
  • By sea
