Food Beverage Flexible Intelligent Multi Lane Packing Machine 4 6 Columns
Food Beverage Flexible Intelligent Multi Lane Packing Machine 4 6 Columns
Food Beverage Flexible Intelligent Multi Lane Packing Machine 4 6 Columns
Food Beverage Flexible Intelligent Multi Lane Packing Machine 4 6 Columns
Specifications
Brand Name :
CS
Model Number :
CS
Certification :
CE
Place of Origin :
Guangdong,China
MOQ :
1
Price :
Price negotiable
Payment Terms :
T/T
Supply Ability :
100 units per month
Delivery Time :
Delivery date negotiable
Packaging Details :
Export wooden box packaging
function :
FILLING, Wrapping, Sealing
packaging type :
Bags, Pouch
packaging material :
Plastic
Voltage :
380V
function FILLING, Wrapping, Sealing packaging type Bags, Pouch packaging material Plastic Voltage 38 :
PASTE, liquid
Weight (KG) :
1500
application :
Food, Beverage
automatic grade :
Automatic
warranty :
1 Year
after-sales service provided :
Video technical support, Field installation, commissioning and training, Online support, Field maintenance and repair service, Free spare parts
Machine Material :
Stainless steel
Power Consumption :
5-8KW
Customized Support :
OEM，ODM
Air Pressure :
0.6MPa
Packing Material :
Plastic film, paper, aluminum foil, etc.
Application :
Food, pharmaceutical, chemical, hardware, etc.
Packing Type :
Pillow bag, gusset bag, stand-up bag, etc.
Bag Size :
Length: 50-300mm, Width: 50-200mm
Weight :
1000-2000kg
Packing Speed :
Up to 200 packs per minute
Number Of Lanes :
2-10 lanes
Air Consumption :
0.4m3/min
Dimension :
3000*1200*1800mm
Power Supply :
220V/380V, 50/60Hz, 3 phase
Description

Flexible And Intelligent Multi Lane Packing Machine For Medium To High Volume Liquid Packaging Needs

The multi-column liquid packaging machine is a highly efficient automated equipment, mainly used to quickly and accurately dispense liquid or semi-fluid products into containers.
Efficient filling
Supports multi-column synchronous operation (such as 4 columns, 6 columns, etc.), and achieves high-speed filling of dozens to hundreds of bottles per minute through pump pressure or gravity filling technology, significantly improving production efficiency.
Accurate metering
Adopting a volumetric metering system (such as a piston pump, flow meter), the filling volume can be adjusted according to demand, and the accuracy can usually reach ±1%, which is suitable for liquids of different viscosities such as water, pastes, sauces, etc.

Main Features

1. lt has SS 304 stainless steel, a strong and long-lasting material.

2. lt usually has an emergency stop, capacity count, and output pack ready.
3. Brand electrical components, more reliable and durable.
4. Automatic slitting film system, the incision is smooth and flat.
Lane number
4/6/8/10/12 Lanes
Measuring range
1-50ml (depend on bag size and packaging material)
Packing speed
30-50 cuts/min
Bag length
Max. 170mm (customized)
Bag width
16-84mm / 16-54mm / 16-40mm / 16-32mm / 16-26mm
Bag type
3/4 side seal bag, back seal bag, irregular shape stick bag
Voltage
380V, 50Hz, 3 Phase
Power
4.5-6.2KW
Air consumption
7L/min
Machine size
Non-standard customization
Machine weight
About 1500kg
