MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
Specifications
Brand Name :
TE
Model Number :
MS5540CM
Place of Origin :
USA
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000pcs
Delivery Time :
5-8 work days
Packaging Details :
Standard packaging
Dimensions :
6.2×6.4 mm
Pressure Measurement Range :
10 - 1100 mbar (1 kPa - 110 kPa)
Resolution :
0.1 mbar
ADC Resolution :
16 - bit
Interface :
3 - wire serial interface
System Clock :
32.768 kHz
Description

MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems

Protection Features:

  • Waterproof gel coating, meeting the 100-meter waterproof requirement for diving watches.
  • Electrostatic discharge (ESD) protection improved to 4 kV for all pins.

Compatibility:

  • Fully compatible with software versions of MS5534C and previous MS5540 models.
  • Form factor compatible with the MS54XX series.

Environmental Compliance:

Lead-free and RoHS compliant.

Typical Applications

  • Mobile altimeters and barometers
  • Meteorological monitoring systems
  • Multifunctional sports watches
  • Diving equipment and watches
  • Mobile water depth detection devices

Sensor Type Absolute - pressure sensor
Dimensions 6.2×6.4 mm
Pressure Measurement Range 10 - 1100 mbar (1 kPa - 110 kPa)
Resolution 0.1 mbar
ADC Resolution 16 - bit
Output 16 - bit digital output, providing digital pressure and temperature values
Interface 3 - wire serial interface
System Clock 32.768 kHz
Operating Temperature Range - 40℃ to 85℃
Supply Voltage 2.2 - 3.6 V
Operating Current < 5 μA
Standby Current < 0.1 μA

MS5540CM Pressure Sensor For Mobile Altimeters Barometers Meteorological Monitoring systems
