26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings
Specifications
Model Number :
26PCGFD6G
Place of Origin :
USA
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000PCS
Delivery Time :
5-8 work days
Packaging Details :
Standard packaging
Accuracy :
0.5%
Supply Voltage :
Generally 10 VDC, with a maximum of 16 VDC
Operating Temperature :
- 40°C to 85°C
Response Time :
1 ms
Resistance :
11.5 kΩ
Number of Pins :
4
Description

26PCGFD6G Pressure Sensor For Water Control Valves To Monitor Water Consumption Of Households Buildings

  • Product Features:
    • The 26PC series of miniature pressure sensors are compact and cost - effective, suitable for wet or dry media.
    • Each sensor contains four active piezoresistors forming a Wheatstone bridge. When pressure is applied, the resistance changes, and the sensor provides a millivolt output signal proportional to the input pressure.
    • With a pressure range of 1 psi to 250 psi and an operating temperature range of - 40ºC to 85ºC, it can be used in a variety of environmental conditions.
    • The sensor is compatible with a variety of wet and dry media that are compatible with polyphthalamide (PPA) plastics and the specified sealing media, and is RoHS compliant.

  • Application Scenarios:
    • It can be used in oxygen concentration meters to measure the pressure of the sieve bed to optimize system performance.
    • It is applicable to dental chairs to control the air pressure in various dental instruments.
    • It can be applied to hemodialysis to monitor the correct pressure and help ensure optimal blood filtration.
    • It is used in respirators to measure the exhaled pressure to ensure correct respiratory analysis.
    • It can be used in water control valves to monitor the water consumption of households and buildings, as well as in irrigation equipment to control the water pressure and flow rate.
    • It is also suitable for filter monitoring to detect whether the filter is blocked and needs to be replaced, and for pressure valves to measure and control the pressure in industrial processes, etc.

Operating Pressure 0.5 - 250 psi5
Accuracy 0.25% (typical range), 0.5% (full range)
Output Type Analog
Mounting Style Through Hole
Package / Case SIP, DIP (also SMT for 1 - 15 psi models)
Operating Power Supply Voltage 10 V
Minimum Operating Temperature - 40°C
Maximum Operating Temperature + 85°C
Response Time 1 ms
Factory Package Quantity 51
Unit Weight 2 g
Full - Scale Range Typically 16.7 mV
Compensation Temperature Range 0°C to 50°C
Input Resistance Min 5.5 kΩ, Typ 7.5 kΩ, Max 11.5 kΩ
