YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor
YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor
YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor
YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor
YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor
YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor
Specifications
Brand Name :
YJJ
Model Number :
MPX5700DP
Place of Origin :
USA
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500
Delivery Time :
5-8 days
Packaging Details :
Plate serving
Price :
Negotiable
Packaging: Unibody :
6-pin
Working power supply voltage :
5V
Operating temperature :
+ 125 ° C
Minimum operating temperature :
-40 ° C
Working power supply current :
7 mA
Output voltage :
4.7V
Description

Product Description:

MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor

Features:

MPX5700DP series piezoresistive sensor is an advanced single crystal silicon sensor. This sensor has A wide range of applications and is particularly suitable for those applications that adopt microcontrollers or microprocessors with A/D inputs. This patented unit sensor combines advanced micro-mechanical technology, thin-film metallization and bipolar processing to provide an accurate high-level analog output signal proportional to the applied pressure.

Characteristics

The error rate within the range of 0℃ to 85℃ is 2.5%

2. It is applicable to systems based on microprocessors or microcontrollers

3. Provide differential pressure and gauge pressure configurations

4. Patented silicon shear stress-strain gauge

5. Durable epoxy one-piece molded components

Brand: Frees

Product type: Board computer interface pressure sensor

Working pressure: 102 psi(range 700Kpa)

Pressure type: Differential pressure

Accuracy: 2.5%

Installation style: Through Hole

Port type: No Ports

Packaging: Unibody 6-pin

Working power supply voltage: 5 V

Operating temperature: + 125 ° C

Minimum operating temperature: -40 ° C

Working power supply current: 7 mA

Output voltage: 4.7V

Packaging: Tray

Series: MPX5700

Packaging quantity: 125

Voltage: 5.25V

Voltage - Minimum: 4.75V

Weight: 1.865 g

Specifications:

Working pressure 102 psi(range 700Kpa)
Accuracy 2.5%
Output type Analog
Installation style Through Hole

YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure SensorYJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor
