320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet
320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet
320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet
320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet
320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet
320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet
Specifications
Brand Name :
X-media
Model Number :
10mm
Certification :
CE/RoHS/ISO/CB/SASO/TUV/FCC/UL
Place of Origin :
China,Shenzhen
MOQ :
5sq.m
Price :
Negotiation
Payment Terms :
T/T, MoneyGram,Cash
Supply Ability :
5,000sq.m/month
Delivery Time :
8~10 working days
Packaging Details :
Flight case, wooden case and carton box and foam package
Product name :
Stadium perimeter led display
Cabinet material :
Alloy metal
Module size :
320x160mm
Screen size :
Customized design
Brightness :
6000cd
Warranty :
5 years
Life time :
100,000H
MTBF :
10,000H
Description

Aluminum Cabinet Stadium Perimeter LED Display P10 Football LED Screen FCC SASO

Support Customized steel support, the quality is very good.
There are over 15 holes , you can make the support at any hole to set suitable height for your project. Rubber hat
There are rubber hat at the top of cabinet, over 5cm customized, it can effectively prevent hit of basketball or soccer.

Soft module mask

We make private mode base on P10 LED display to production soft module mask, it can protect the led display avoid hit better.

Parameter specification

model P8 P10
Pixel unit module Pixel pitch(mm) 8 10
Pixel density (dots/sqm) 15625 10000
LED type SMD SMD
Module size(mm) W320xH160 W320×H160
Pixel composing RGB full color RGB full color
Pixel unit screen screen size(mm) 960*960mm 960*960mm
module Resolution (nits) 32*16 32*16
Cabinet structure Water-proof Water-proof
screen material Ironed steel cabinet Ironed steel cabinet
Protect degree IP65 front ,IP54 rear IP65 front ,IP54 rear
Viewing distance(m) 8-100m 10~100m
Brightness(cd/sqm) ≥6000 cd/sqm ≥6000 cd/sqm
Power consumption (w/sqm) Max 850W/sqm ,Min 280W/sqm Max 600W/sqm ,Min 200W/sqm
Driving IC 1/4 scan MBI Brand Driver 1/4 scan MBI Brand Driver
Refresh rate(HZ) ≥960-2000 ≥960-2000
Viewing angel(c) H120 V120 H120 V120
Other parameter Image adjustment contrast, tonal, the color saturation, gray calibration coefficient, color range, image variable times, etc
Image processing Video noise reduction, fast motion compensation, edge to sharpen, edge smooth, color space transformation and control, coordinate transformation of grey scale, etc
Brightness uniformity The whole screen on the monochrome, minimum pixel luminance and the brightest pixel luminance than more than 0.9
Gray 65536
Color temperature/contrast Red, green, and blue brightness and contrast can through the software level 100 adjustable, color temperature can be adjusted according to need
Transmitting Distance The shielded twisted-pair cable transmission distance for 100 meters, the biggest up to 140 m. Multimode fiber of up to 500 meters, the single-mode optical fiber to 20 kilometers
Input Signal RF,S-VIDEO,RGBTV,YUT,YC,COMPOSITION
Control System PCTV non-liner editing card+DVI display card+main control card+optic fiber transmission(Optional) or video dealer
Average No Failure Time 20000 hours 20000 hours
Life span 100,000 hours 100,000 hours
Out-of Control rate 0.0001 0.0001
To floor drain current Less than 3.5MA Less than 3.5MA
Control system Synchronized Synchronized
Operating Environment Temperature -20°C—65°C Optional -20°C—65°C Optional

320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet

320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet

320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet

Buying Guides
In order to offer you a suitable solution, please follow the guides bellowing:
1, Star effect or video effect which you need.
2, Dimension ( Width and Height)
3, Location of installation ( picture is best)
4, Purpose. ( what are you going to do with the LED Curtain)

After-Sale Service
1. Three year warranty, Lifetime free maintenance.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
6. Special service for big project, such as stadium, exhibitions, squares and so on.

Company profile

320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet

FAQ

Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Indoor & Outdoor P2.97mm/ P3.91mm/ P4.81mm)
Q2: Where is it used for?
A2: Indoor & Outdoor rental use. Widely used for backdrop of stage events, rental / hire business, liveshow, concerts, conference room, etc.
Q3: Can it play HD video?
A3: Yes, it can realize high definition video function with Novastar / Linsn / Huidu controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.

X-Media the professional manufacturer of outdoor, indoor LED Display Screen, LED Panel , LED Wall in Shenzhen, China with led display exported to more than 100 countries and regions, passed CE, ROHS, FC Certifications.
is a good choice for your permanent install LED display needs and events rental led screen needs



Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea, air or DHL, multiple shipping ways for your choice.

320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet

X-Media is the professional manufacturer of outdoor, indoor LED Display Screen, LED Panel, LED Wall in Shenzhen, China with led display exported to more than 100 countries and regions, passed CE,ROHS FC Certifications.
is a good choice for your permanent install LED display needs and events rental led screen needs

1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.

320x160mm Stadium Perimeter LED Display Ironed Steel Cabinet


In-sale service:

1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.

After-sale service:

1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.

If you are interested, pls add my whatsapp for more detailed pictures and video !
