Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC
Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC
Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC
Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC
Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC
Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC
Specifications
Brand Name :
Siemens
Model Number :
CS1W-BC083
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
2-3 days
Product Name :
PLC Industrial Control
Part Number :
CS1W-BC083
Shipment :
DHL
Condition :
New
Lead Time :
2-3 days
WQR12038HBL :
1 year
Keywords :
CS1W-BC083
Description
Sinamics CS1W-BC083 Overview

The CS1W-BC083 is an 8‑slot CPU backplane designed for Omron SYSMAC CS1 and CS series programmable controllers. It provides reliable electrical connectivity and mechanical mounting for CPU, power supply, I/O, and special modules, supporting both CS-series and C200H I/O units for flexible system configuration. With robust construction, standard DIN rail/panel mounting, and global safety certifications, this backplane delivers stable performance for factory automation, machinery control, and process control systems. Its 8‑slot layout supports modular expansion while maintaining compact installation and easy wiring, making it a core component for building reliable and scalable PLC control systems.










Figure 1 shows the front panel of CS1W-BC083.

Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC










Omron CS1W-BC083 8-Slot CPU Backplane for CS1 Series PLC













Quick Specs.

Table 1 shows the Quick Specs

Item Details
Part Number CS1W-BC083
Brand Omron
Type CPU Backplane
Slots 8
Series SYSMAC CS1 / CS
Compatibility CS1 CPU, C200H I/O Units
Mounting DIN Rail / Panel
Certifications CE, UL, RoHS





Detailed Specification
Parameter Value
Manufacturer Omron Automation
Product Type CPU Backplane / Base Unit
Number of Slots 8 slots
Compatible Series SYSMAC CS1, CS series, C200H I/O modules
Suitable CPU CS1-series CPU Units
Current Consumption 5 V DC, 0.11 A
Dimensions (W×H×D) 435 × 135 × 123 mm
Weight Approx. 1.2 kg
Mounting Method DIN rail mounting, Panel mounting
Standards CE, UL, CSA, RoHS compliant
Operating Temperature 0°C to +55°C
Storage Temperature -20°C to +65°C
