Specifications
Brand Name :
Siemens
Model Number :
MR-J4-350A
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
2-3 days
Product Name :
PLC Industrial Control
Part Number :
MR-J4-350A
Shipment :
DHL
Condition :
New
Lead Time :
2-3 days
Warranty :
1 year
Keywords :
MR-J4-350A
Description
Siemens MR-J4-350A Overview

The Mitsubishi MR-J4-350A is a high-performance 3.5kW AC servo amplifier belonging to the industry-leading MELSERVO-J4 product line, engineered for precise and responsive motion control across industrial automation applications. Designed to deliver stable torque and speed regulation, this servo amplifier is equipped with a built-in dynamic brake and regenerative resistor, eliminating the need for external components and reducing installation complexity and space requirements.








Figure 1 shows the front panel of HA300NC-S1.

Mitsubishi MR-J4-350A MELSERVO-J4 3.5kW AC Servo Amplifier | High Precision Industrial Servo Drive







Mitsubishi MR-J4-350A MELSERVO-J4 3.5kW AC Servo Amplifier | High Precision Industrial Servo Drive


















Quick Specs.

Table 1 shows the Quick Specs.

Item Specification
Model MR-J4-350A
Series MELSERVO-J4
Product Type AC Servo Amplifier
Rated Output 3.5kW
Input Voltage 3-phase 200-240VAC, 50/60Hz
Rated Output Current 17A
Dynamic Brake Built-in
Regenerative Resistor Built-in
Communication RS-422/RS-485
Protection Class IP20
Max Ambient Temperature 0-55°C





Detailed Specification

Category Parameters Details
Basic Information Model MR-J4-350A

Series MELSERVO-J4

Type AC Servo Amplifier

Command Interface Generic Interface
Electrical Specifications Rated Output Power 3.5kW

Rated Output Current 17A

Main Circuit Voltage 3-phase AC 200-240V, 50/60Hz (Allowable: 170-264VAC)

Control Circuit Voltage Single-phase AC 200-240V, 50/60Hz (Allowable: 170-264VAC)

Interface Power Supply DC24V±10%, 0.5A
Functional Features Dynamic Brake Built-in

Regenerative Resistor Built-in

Communication Interface RS-422/RS-48

Max Command Pulse Frequency 4Mpulses/s (Differential Receiver), 200kpps (Open Collector)

Encoder Resolution 22-bit (4,194,304 p/rev)

Control Modes Position, Speed, Torque Control
Physical & Environmental Protection Class IP20

Operating Temperature 0 to +55°C

Storage Temperature -20 to +65°C

Weight 2.3 kg
