RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
Specifications
Brand Name :
Siemens
Model Number :
RK112A-11
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
2-3 days
Product Name :
PLC Industrial Control
Part Number :
RK112A-11
Shipment :
DHL
Condition :
New
Lead Time :
2-3 days
Warranty :
1 year
Keywords :
RK112A-11
Description
Siemens RK112A-11 Overview

The RK112A-11 10G SFP+ LC Single-mode Transceiver Module (1310nm, 10km, DOM) is a high-performance, cost-effective optical transceiver designed for 10 Gigabit Ethernet and fiber channel applications. Compliant with SFF-8431 and SFF-8472 industry standards, it delivers reliable data transmission at a rate of 9.953–10.3125 Gbps over 10km of single-mode fiber (SMF, G.652) with a center wavelength of 1310nm.









Figure 1 shows the front panel of RK112A-11.

RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission








RK112A-11 10G SFP+ LC Single-mode Transceiver Module with 10Gbps Speed 1310nm Wavelength and 10km Transmission
















Quick Specs.

Table 1 shows the Quick Specs.

Item Specification
Form Factor SFP+
Data Rate 10Gbps
Wavelength 1310nm
Transmission Distance 10km (single-mode fiber)
Connector Type LC duplex
Digital Monitoring DOM (Digital Optical Monitoring) supported





Detailed Specification
Parameter Category Parameter Name Specification
Optical Parameters Center Wavelength 1310nm ±20nm

Minimum Transmit Power -8.5 dBm

Maximum Transmit Power -1.5 dBm

Receive Sensitivity -17 dBm (max)

Link Distance 10km (SMF, G.652)
Electrical Parameters Data Rate Range 9.953 - 10.3125 Gbps

Power Supply Voltage 3.3V ±5%

Power Consumption ≤1.2W
Mechanical & Environmental Form Factor SFP+ (Compliant with SFF-8431, SFF-8472)

Connector Type LC duplex (unplated)

Operating Temperature 0°C ~ 70°C (Commercial Grade)

Storage Temperature -40°C ~ 85°C
Functional Features Digital Optical Monitoring (DOM) Yes (supports real-time parameter monitoring)

Compliance Standards RoHS, CE, FCC
