Siemens 6ES7323-1BH0-0AA0 Overview

The SIMATIC S7-300 SM 323 Digital I/O Module (6ES7323-1BH00-0AA0) is a high-performance, compact I/O solution designed for Siemens S7-300 PLC systems, ideal for industrial automation and control applications. Featuring 8 digital inputs (DI) and 8 digital outputs (DO) with 24V DC operation, this module delivers reliable signal processing for connecting sensors, actuators, and other field devices in factory floors, manufacturing lines, and process control environments.







Figure 1 shows the front panel of 6ES7323-1BH0-0AA0.

6ES7323-1BH00-0AA0-SIMATIC S7-300 Digital Module SM 323, Optically Isolated, 8DI & 8DO, 24V DC, 0.5A







6ES7323-1BH00-0AA0-SIMATIC S7-300 Digital Module SM 323, Optically Isolated, 8DI & 8DO, 24V DC, 0.5A










Quick Specs.

Table 1 shows the Quick Specs.


Specification Details
Product Model 6ES7323-1BH00-0AA0
Module Type Digital I/O Module (SM 323)
I/O Configuration 8 DI, 8 DO
Voltage 24V DC
Current per Channel 0.5A
Total Current 2A
Isolation Optically Isolated
Connector 1x20-pole
Compatibility SIMATIC S7-300
Power Loss Typ. 3.5W





Detailed Specification
Parameter Details
Ordering Number 6ES7323-1BH00-0AA0
Product Series SIMATIC S7-300
Module Name SM 323 Digital I/O Module
Isolation Optically Isolated
Digital Inputs (DI) 8 channels, IEC 61131-2 Type 1
Digital Outputs (DO) 8 channels, push-pull
Input Voltage 24V DC (20.4V-28.8V DC)
Output Voltage 24V DC (20.4V-28.8V DC)
Output Current per Channel 0.5A (continuous), 2A (peak, 10ms)
Total Output Current 2A
Input Current (No Load) Max. 40mA (from L+), Max. 40mA (from backplane bus 5V DC)
Power Loss Typ. 3.5W
Operating Temperature 0°C to 60°C
Storage Temperature -25°C to 85°C
Dimensions (W x H x D) 40mm x 125mm x 150mm
Certification CE, UL, CSA
Connector Type 20-pin
