Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
Specifications
Brand Name :
Siemens
Model Number :
Q35B
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
2-3 days
Product Name :
PLC Industrial Control
Part Number :
Q35B
Shipment :
DHL
Condition :
New
Lead Time :
2-3 days
WQR12038HBL :
1 year
Keywords :
Q35B
Description
Sinamics Q35B Overview

The Mitsubishi Q35B is a compact, high-reliability 5-slot main base unit designed for the MELSEC-Q Series PLC system. It provides a stable backplane for installing power supply, CPU, and I/O or intelligent function modules, supporting flexible system configuration for small-to-medium industrial automation equipment. With robust construction and standard compatibility, the Q35B ensures stable signal transmission and easy installation, widely used in packaging machinery, assembly lines, and small machine tools. It enables expandable control systems while saving cabinet space, making it an ideal backbone for reliable and cost-effective PLC setups.









Figure 1 shows the front panel of Q35B.

Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series










Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series












Quick Specs.

Table 1 shows the Quick Specs

Item Details
Model Q35B
Series MELSEC-Q
Type Main Base Unit
Slots 5
Weight 0.27 kg









Detailed Specification
Parameter Value
Product Type Main Base Unit / Backplane Rack
Series MELSEC-Q Series
Total Slots 5
Power Supply Slot 1
CPU Slot 1
I/O Slots 3
Extendable Yes
Compatible Modules Q Series I/O, analog, positioning, intelligent modules
Internal Current Consumption (DC 5V) 0.11 A
Mounting M4 screw hole / φ4.5 hole; DIN rail with Q6DIN2 adapter
Dimensions (W×H×D) 245 mm × 98 mm × 44.1 mm
Weight 0.27 kg
Operating Temperature 0–55°C
Storage Temperature -20–70°C




Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
Mitsubishi Q35B PLC Base Unit 5-Slot Main Base Rack for MELSEC-Q Series
