Specifications
Brand Name :
PUNAISGD
Model Number :
GYFXTY-16b1.3
Certification :
CE/ROHS/ISO9001
Place of Origin :
Guangdong, China
MOQ :
1km
Price :
negociate
Payment Terms :
T/T,Western Union
Supply Ability :
1000000km/month
Delivery Time :
7days
Packaging Details :
woode drum
Type :
GYFXTY-16b1.3
Cores :
16 fibers
Fiber Brand :
Corning, OFS, YOFC
Construction :
Central Loose Tube
Useful :
Outdoor Fiber Optic Cable
Transport Package :
Wooden Drum
Cable Dimension :
7mm
Jacket Color :
Black
Mode :
Singlemode G652D
Out Sheath :
PE sheath
Strengthen Member :
2pcs FRP
Name :
Outdoor Fiber Optic Cable
Description
Outdoor Fiber Optic Cable GYFXTY Type With 2 Parallel Frp Uni-tube 4F 6F 12F Span

DescriptionUni-Tube All Dielectric Aerial Drop cable is specifcally designed for Fiber-to -the-Subscriber applications. It is a round, all dielectric cable ideally suited for self-supporting drop-type installations as well as in lashed or conduit builds. The overall glass yarn strength member is used for additional mechanical protection.


Temperature Range

Operating : -40ºC to +70ºC
Storage : -50ºC to +70ºC
Installation : -30ºC to +70ºC
Bending Radius:
Static 10D
Dynamic 20D

Features

Small size, Low cost. Up to 24 fibers.
Uni-tube gel-filled construction for superior fiber protection.
Two parallel FRP wire and overall glass yarn to enhance tensile resistant. and protect cable from mechanical damage.
Designed for use with inexpensive attachment hardware. Self-supporting no messenger needed.


Applications
Conduit, Duct, Aerial/Lashed.
FTTx, Access.

Option
FRP or KFRP strength member can be choosed .
Glass yarn or Aramid yarn can be choosed.


OPTICAL CHARACTERISTICS


G652
50/125μm
62.5/125μm


Attenuation
(+20℃)
@850 nm

<=3.0dB/km
<=3.3dB/km
@1300 nm

<=1.0dB/km
<=1.0dB/km
@1310 nm
<=0.36dB/km


@1550 nm
<=0.22dB/km


Bandwidth
(Class A)
@850 nm

>=500 MHz*km
>=200 MHz*km
@1300 nm

>=1000 MHz*km
>=600 MHz*km
Numerical Aperture

0.200+-0.015NA
0.275+-0.015NA
Cable cut-off wavelength
<=1260 nm





Cable Count Out sheath Weight Minimum allowable Tensile Strength
minimum allowable Crush Load
Minimum Bending Radius
Storage
Diameter (N) (N/100mm) (MM) temperature
(MM) (KG) short term long term short term long term short term long term (℃)
2 7.2 45 1200 500 1000 300 20D 10D 20
4 7.2 45 1200 500 1000 300 20D 10D 20
6 7.2 45 1200 500 1000 300 20D 10D 20
8 7.2 45 1200 500 1000 300 20D 10D 20
12 7.2 45 1200 500 1000 300 20D 10D 20
