outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
Specifications
Brand Name :
PUNAISGD
Model Number :
ASU-8b1.3
Certification :
CE/ROHS/ISO9001
Place of Origin :
Guangdong, China
MOQ :
1km
Price :
negociate
Payment Terms :
T/T,Western Union
Supply Ability :
1000000km/month
Delivery Time :
7days
Packaging Details :
woode drum
Type :
ASU-6b1.3
Cores :
8 fibers
Strength Member Material :
FRP
Construction :
Central Loose Tube
Useful :
Outdoor Fiber Optic Cable
Transport Package :
Wooden Drum
Cable Dimension :
6.8mm
Jacket Color :
Black
Mode :
Singlemode G652D
Name :
Outdoor Fiber Optic Cable
Description

outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY

Application:

Telecommunications Industry
Local area network FTTH, FTTX deployments
Optical Fiber Signal Transmission
Fiber Optic Sensing CATV

Features:

Small Size and Ligth Weight
Two FRP as strength member to provide good tensile performance
Gel Filled or gel free , good waterproof performanceASU 80m 100m 120m span customized
Fiber Color
No.
1
2
3
4
5
6
Color
Blue
Orange
Green
Brown
Gray
White
No.
7
8
9
10
11
12
Color
Red
Black
Yellow
Violet
Pink
Aqua
Fiber count
1-12
Span(m)
80
120
Strength Member Material
FRP
Strength Member Diameter
2.0mm
2.5mm
Strength Member Number
2
2
Loose Tube Material
PBT
Loose Tube Diameter(mm)
2.1mm
2.5
Filling compound in loose tube
Thixotropic jelly
Water blocking Material
Water blocking yarn
Outer Sheath Material
Black HDPE
Outer Sheath Thickness(mm)
1.0
1.0
Outer Diameter(mm)
6.8
8.0
Cable Weight(kg/km)
Approx.44
Approx.62
Short term tensile(N)
850
1250


outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY

Details Images
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY


Installation Instructions

outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
Product Paramenters
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY


Company Profile
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
Product packaging
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
Our Advantages
outdoor ASU 80M 120M 2 4 6 8 12 16 24 core hilo 2fo 4fo 12fo 24fo 4f span 80m 120m Anatel Mini ADSS ASU cable fibra optica GYFFY
