GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
Specifications
Brand Name :
PUNAISGD
Model Number :
GYXTC8Y-12B1.3
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
1km
Price :
negociate
Payment Terms :
T/T,Western Union
Supply Ability :
1000000km/month
Delivery Time :
7days
Packaging Details :
woode drum
Type :
GYXTC8Y-12B1.3
Crush Resistance :
1000N/2000N/3000N
Central Strength Member :
FRP or Steel Wire
Fiber Model :
G652D
Temperature :
-20 to 70°C
Cable Diameter :
7.0mm
Manufacturer :
Yes
Name :
Outdoor Fiber Optic Cable
Description

GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable

GYXTC8Y cable is for tough outdoor use. It provides robust aerial applications. Central member increases strength greatly. Inside, a loose tube holds fibers. Water-blocking material creates secure protection. So, you gain increased moisture resistance. Corrugated steel tape provides radial strength. Finally, a black PE jacket covers all. Cables have 125.0±0.1µm fiber cladding. Fiber diameter measures 242±7 µm.

The fiber features a figure-8 shape. You can locate the support easily. Diameter is (8.0 ±0.20mm) (15.0 ±0.20mm). Stranded wire is 1.0mm7 strands. PBT tube thickness is 0.3±0.05mm. Also, tube diameter is 2.5±0.1 um. Steel tape is 0.15±0.015 thick. Corrugated steel measures 0.4 ±0.015. Outer covering provides great UV protection.


Specification
Part NO:
Increased by 2 fiber
Fiber Count
Tubes
Fillers
cable OD(mm)
Cable Weight(kg/km)
GYTC8S -2~6
2~6
1
4
10.2*19.8
204
GYTC8S -8~12
8~12
2
3
10.2*19.8
204
GYTC8S -14~18
14~18
3
2
10.2*19.8
204
GYTC8S -20~24
20~24
4
1
10.2*19.8
204
GYTC8S-26~30
26~30
5
0
10.2*19.8
204
GYTC8S -32~36
32~36
6
0
10.8*20.4
225
GYTC8S -38~48
38~48
4
1
11.5*21.1
236
GYTC8S -50~60
50~60
5
0
11.5*21.1
236
GYTC8S -62~72
62~72
6
0
12.3*21.9
270
GYTC8S -74~84
74~84
7
1
13.1*22.7
283
GYTSC8S-86~96
86~96
8
0
13.8*23.4
299
GYTC8S -98~108
98~108
9
1
14.6*24.2
319
GYTC8S -110~120
110~120
10
0
15.4*25
340
GYTC8S -122~132
122~132
11
1
16.2*25.8
361
GYTC8S-134~144
134~144
12
0
16.9*26.5
380


GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable

GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable

Details Images
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable


Installation Instructions

GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
Product Paramenters
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable


Company Profile
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
Product packaging
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
Our Advantages
GYXTC8Y GYFXTC8Y Self Supporting Aerial Fiber Optic Cable
