Specifications
Brand Name :
PUNAISGD
Model Number :
GYFXTY-6b1.3
Certification :
CE/ROHS/ISO9001
Place of Origin :
Guangdong, China
MOQ :
1km
Price :
negociate
Payment Terms :
T/T,Western Union
Supply Ability :
1000000km/month
Delivery Time :
7days
Packaging Details :
woode drum
Type :
GYFXTY-6b1.3
Cores :
6 fibers
Strength Member Material :
FRP
Construction :
Central Loose Tube
Useful :
Outdoor Fiber Optic Cable
Transport Package :
Wooden Drum
Cable Dimension :
6.8mm
Jacket Color :
Black
Mode :
Singlemode G652D
Name :
Outdoor Fiber Optic Cable
Description
Best-Selling GYFXTBY Mini Span GYFXTY GYTA GYTS Fiber Optic Cable Amoured 4-24 Cores Flat Drop Cable Gyfxtby Fiber Optic Cable

optical cables that resistant to biological hazards caused by rodents,termites and birds,etc. after installation.Optical cables are often damaged by rodents.Termites not only bite,but also release formic acid to the cables.We design methods include physical(include metallic and glass fiber armor and nylon sheath) and chemical methods(Spicy additives ) agsinst biological hazards



■ Fatures:

  • Accurate process control ensuring good mechanical and temperature performances

  • The material of loose tubes with good hydrolysis resistance and high strength

  • Tube filling compound providing the key protection for fibres

  • Excellent crush resistance and flexibility

  • Non-Metallic FRP wires armors providing excellent anti-rodent performance

OPTICAL CHARACTERISTICS


G652
50/125μm
62.5/125μm


Attenuation
(+20℃)
@850 nm

<=3.0dB/km
<=3.3dB/km
@1300 nm

<=1.0dB/km
<=1.0dB/km
@1310 nm
<=0.36dB/km


@1550 nm
<=0.22dB/km


Bandwidth
(Class A)
@850 nm

>=500 MHz*km
>=200 MHz*km
@1300 nm

>=1000 MHz*km
>=600 MHz*km
Numerical Aperture

0.200+-0.015NA
0.275+-0.015NA
Cable cut-off wavelength
<=1260 nm





Cable Count Out sheath Weight Minimum allowable Tensile Strength
minimum allowable Crush Load
Minimum Bending Radius
Storage
Diameter (N) (N/100mm) (MM) temperature
(MM) (KG) short term long term short term long term short term long term (℃)
2 7.2 45 1200 500 1000 300 20D 10D 20
4 7.2 45 1200 500 1000 300 20D 10D 20
6 7.2 45 1200 500 1000 300 20D 10D 20
8 7.2 45 1200 500 1000 300 20D 10D 20
12 7.2 45 1200 500 1000 300 20D 10D 20
