1.32 Inch Monochrome OLED Display 128x96 SSD1327Z With Grayscale 4 Wire Spi Interface Screen
1.32 Inch Monochrome OLED Display 128x96 SSD1327Z With Grayscale 4 Wire Spi Interface Screen
Specifications
Brand Name :
Limito
Model Number :
VG-2896GSWEG01
Place of Origin :
China
Certification :
RoSH, Reach
MOQ :
10pcs
Price :
Negotiable
Packaging Details :
Cartons, Capboard, EPE, Blister Tray.
Delivery Time :
3-5days
Payment Terms :
T/T, Paypal
Supply Ability :
7kk/M
Diagonal Screen Size :
1.32
Drive IC :
SSD1327Z
Interface :
4-wire spi
Life Time :
100,00
Operating Temperature :
-40~70°C
Number of Pixels :
128x96
Brightness :
80
Description

1.32 Inch Oled White 128x96 LCD SSD1327Z Driver With Grayscale Oled Module 4-Wire Spi Interface Screen

LIMITO OLED Description:

OLED (Organic Light Emitting Display) refers to the phenomenon when several organic thin films are placed between an anode and a cathode, under a positive bias voltage, a bright light is emitted from the anode side via a process of carrier injection, transfer, and recombination.

LIMITO OLED Specification:

Part Name: OLED Display Module
Limito Part ID: VG-2896GSWEG01
Display Mode: Passive Matrix
Display Color: Monochrome (White)
Drive Duty: 1/96 Duty
Number of Pixels: 128*96
Module Size:
 31.50x 78.47 X 1.70(mm)
Panel Size:
31.50x 26.70x 1.4(mm)
Active Area: 26.86 x 20.14 (mm)
Pixel Pitch: 0.21 x 0.21(mm)
Pixel Size: 0.19 x 0.19 (mm)

LIMITO OLED Mechanical Drawing

1.32 Inch Monochrome OLED Display 128x96 SSD1327Z With Grayscale 4 Wire Spi Interface Screen

LIMITO is OLED Display module supplier,it’s a market leader and pioneer in OLED solutions which include Transparent OLED,Flexible OLED,Monochrome OLED,Character OLED,Segment OLED,Area Color OLED, Full color OLED,Customizedized design products ect.

LIMITO OLED Benefits:

High Contrast Ration(10,000:1)

Free Viewing Angle

Fast Response Time(<15us)

Thinner & Lighter & Durable

Wide operation Temperature-40°c~+85°c

Self-emitting, no need for a backlight

LIMITO OLED Application:

Industrial: Mearusring& meter, OA Equipment, POS & Server Card Reader, Door Security, USB Key

Communication: Mobile Phone, Bluetooth Device, Router, Set-Top Box

Automotive: Head Up display, Car Audio, Speed Detector, ECT, Timer, Climate Control, Dashboard

PC peripheral: Keyboard, Mouse, Printer, Scanner, NAS, Digital Pen

Medical: Glucose Meter, Oximeter, Blood-pressure Meter, Beauty & Cosmetic Equipment

Consumer: IoT, E-Cigarette, Wearable Device, Remote Controller, Game Machine, Digital Camera, Audio Video Equipment
