2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels
Specifications
Brand Name :
Limito
Model Number :
UG- 5664GLBHG01
Place of Origin :
China
Diagonal Screen Size :
2.08
Drive IC :
SH1122
Interface :
8-bit 68XX/80XX Parallel, 3/4-wire SPI, i2c
Life Time :
20000
Operating Temperature :
-40~70°C
Number of Pixels :
256x64
Brightness :
150
Certification :
RoSH, Reach
MOQ :
10pcs
Price :
Negotiable
Packaging Details :
Cartons, Capboard, EPE, Blister Tray.
Delivery Time :
3-5days
Payment Terms :
T/T, Paypal
Supply Ability :
7kk/M
Description

2.08 Inch 256x64 24 Pin SH1122 PMOLED Small OLED Display

LIMITO OLED Description:

The 2.08-inch PM-OLED display panel is a product that emits light itself, without a touchscreen. It features an operating temperature range of -40 ~ 70°C , a storage temperature range of -40 ~ 85°C . It's general features are summarized in the following: Wide Temperature, Matte . Based on its features, we recommend that this model be applied to Handheld & PDA, Wearable etc. Built-in SH1122 driver IC.

LIMITO OLED Specification:

Part Name: OLED Display Module
Limito Part ID:
UG- 5664GLBHG01
Display Mode: Passive Matrix
Display Color: Monochrome with 16 Gray Scales(Light Blue)
Drive Duty: 1/64 Duty
Number of Pixels: 256 X 64
Module Size: 82.50 x 19.00 x 1.60 (mm)
Panel Size:
60.50 x 19.00 x 1.60 (mm) including "Anti-Glare Polarizer'
Active Area: 51.18 x 12.78 (mm)
Pixel Pitch: 0.20 x 0.20 (mm)
Pixel Size: 0.18 x 0.18 (mm)

LIMITO OLED Mechanical Drawing

2.08 Inch Small OLED Display Oled Graphic Display 24 Pin SH1122 PMOLED 256x64 Pixels

LIMITO is OLED Display module supplier,it’s a market leader and pioneer in OLED solutions which include Transparent OLED,Flexible OLED,Monochrome OLED,Character OLED,Segment OLED,Area Color OLED, Full color OLED,Customizedized design products ect.

LIMITO OLED Benefits:

High Contrast Ration(10,000:1)

Free Viewing Angle

Fast Response Time(<15us)

Thinner & Lighter & Durable

Wide operation Temperature-40°c~+85°c

Self-emitting, no need for a backlight

LIMITO OLED Application:

Industrial: Mearusring& meter, OA Equipment, POS & Server Card Reader, Door Security, USB Key

Communication: Mobile Phone, Bluetooth Device, Router, Set-Top Box

Automotive: Head Up display, Car Audio, Speed Detector, ECT, Timer, Climate Control, Dashboard

PC peripheral: Keyboard, Mouse, Printer, Scanner, NAS, Digital Pen

Medical: Glucose Meter, Oximeter, Blood-pressure Meter, Beauty & Cosmetic Equipment

Consumer: IoT, E-Cigarette, Wearable Device, Remote Controller, Game Machine, Digital Camera, Audio Video Equipment
