2.08 Inch 256x64 24 Pin SH1122 PMOLED Small OLED Display

LIMITO OLED Description:

The Organic Light-Emitting Diode (OLED) is a new generation technology, brighter and clearer images with more agile responding speed. This OLED 2.8" inch model no. UG-5664ASWDF01 OLED display is made of 256 x 64 dots individual mono color. This OLED module is lightweight, low power and small, there are different interfaces optional; it is default 3 and 4 lines SPI interface. The module is made of COB OLEDs have the advantages of easily fixed modules on Customizedizeders’ applications because of having PCB board on it.

UG-5664ASWDF01 is a dot matrix 256x64 COF graphic type passive matrix OLED display module. The size of the active area is 2.8” diagonal with module dimension 84.00 X 45.80 (mm). This 2.8 inches OLED display has built-in IC SSD1322U. There are many interface options to choose from, including 6800, 8080 and SPI interface. Logic supply voltage ranges from -0.5V-2.75V. The available emitting colors are white and support grayscale. It is great for the application such as medical device, POS system, white goods, home applications, industrial instrument, automation, audio/visual display systems, personal care appliances, household goods, automobile displays, Dynamic information displays etc.

LIMITO OLED Specification:

LIMITO OLED Mechanical Drawing

LIMITO is OLED Display module supplier,it’s a market leader and pioneer in OLED solutions which include Transparent OLED,Flexible OLED,Monochrome OLED,Character OLED,Segment OLED,Area Color OLED, Full color OLED,Customizedized design products ect.

LIMITO OLED Benefits:

High Contrast Ration(10,000:1)

Free Viewing Angle

Fast Response Time(<15us)

Thinner & Lighter & Durable

Wide operation Temperature-40°c~+85°c

Self-emitting, no need for a backlight

LIMITO OLED Application:

Industrial: Mearusring& meter, OA Equipment, POS & Server Card Reader, Door Security, USB Key

Communication: Mobile Phone, Bluetooth Device, Router, Set-Top Box

Automotive: Head Up display, Car Audio, Speed Detector, ECT, Timer, Climate Control, Dashboard

PC peripheral: Keyboard, Mouse, Printer, Scanner, NAS, Digital Pen

Medical: Glucose Meter, Oximeter, Blood-pressure Meter, Beauty & Cosmetic Equipment

Consumer: IoT, E-Cigarette, Wearable Device, Remote Controller, Game Machine, Digital Camera, Audio Video Equipment
