Specifications
Packaging Details :
Nude Packed（Adjust according to the needs of different export countries）.
Transmission :
DUTEC FCGA140B Automatic Transmission
Price :
Pricing Tailored to Your Needs
Overall Dimension :
6890×2440×2770 mm (ground to seat)
Supply Ability :
Unlimited
Obstacle Crossing Height :
570mm
Delivery Time :
5-7 working days; large orders depend on the factory's schedule.
GVW (Gross Vehicle Weight) :
20000kg
MOQ :
1
Engine :
ISDe300 40
Description

The 4x4 heavy-duty off-road chassis offers superior cross-country performance. Equipped with high ground clearance and great wading capacity, it adapts to harsh terrain. With a 20-ton gross weight, it can be refitted into multiple special vehicles. Robust structure ensures stable operation, making it an ideal platform for overseas export.

4×4 Off-road Heavy Duty Truck Chassis with ISDe300 Engine, Automatic Transmission For Export

Basic Configuration
Engine ISDe300 40
Frame 860*212, thickness 8mm, partially reinforced
Axle 7T/13T
Transmission DUTEC FCGA140B Automatic Transmission
Transfer Case High and Low Range
Tire 365/80R20 (4 pcs)
Detailed Parameters
Overall Dimension 6890×2440×2770 mm (ground to seat)
GVW (Gross Vehicle Weight) 20000kg
Payload N/A
Track Width 1990mm
Displacement 6.7L
Minimum Ground Clearance 355mm
Obstacle Crossing Height 570mm
Approach Angle 26°
Front Overhang / Rear Overhang 1220/1670mm
Max Speed 85km/h
Leaf Spring 11/12 pieces
Chassis Curb Weight 5150kg
Wheelbase 3800mm
Maximum Power 221kW
Fuel Tank Capacity 300L
Wading Depth 570mm
Torque 1100N·m
Departure Angle 32°
Frame Top Surface Height from Ground 1260mm
Drive Type 4×4

Note:Specifications are for reference only, subject to the actual vehicle.
