Specifications
Packaging Details :
Nude Packed（Adjust according to the needs of different export countries）.
GVW :
15000kg
Supply Ability :
Unlimited
Engine :
B170 33
Delivery Time :
5-7 working days; large orders depend on the factory's schedule.
Overall Dimensions :
7240×2500×2720mm
MOQ :
1
Obstacle height :
470mm
Price :
Pricing Tailored to Your Needs
Transmission :
Five gears (Manual)
Description

Dongfeng 4×4 flathead off-road chassis is fitted with B170 power unit and 5-speed manual gearbox matched with two-speed transfer case. The double-layer frame and leaf spring suspension guarantee structural strength. With 3800mm wheelbase and solid off-road parameters, it adapts to complex terrain. Reserved ample space for upper body assembly and supports diversified custom refitting for overseas special vehicle projects.

Dongfeng 4×4 Flathead Off-road Truck Chassis with B170 Engine For Export Custom Refit

Basic Configuration
Engine B170 33
Cab Flathead single row
Frame 860×250, double-layer
Axle 5T/10T
Transmission Five gears
Transfer case High and low speed
Suspension Leaf spring 9/8+10
Tyres 10.00R20 (6+1)
Detailed Parameters
Overall Dimensions 7240×2500×2720mm
Superstructure length ≥4570mm
Wheelbase 3800mm
Trackwidth 1850/1780mm
GVW 15000kg
Chassis Curb weight 5230kg
Approach Angle 24°
Departure Angle 22°
Fuel Tank Capacity 260L
Distance from ground to top of frame rear 1160mm
Fording depth 560mm
Obstacle height 470mm
Max Speed 85km/h
Minimum ground clearance 260mm

Note:Specifications are for reference only, subject to the actual vehicle.
