AZ31B Magnesium Plate (51×45×222mm, H112)

Product Overview

Standard Designations & Core Material Foundation

• Alloy Grade: AZ31B (Mg-Al-Zn Wrought Magnesium Alloy)
• Key Specification:
  • Dimensions: 51mm (thickness) × 45mm (width) × 222mm (length)
  • Tolerance: ±0.1mm (thickness), ±0.2mm (width/length)
  • Supply Condition: H112 (hot-rolled, stress-relieved)


• Chemical Composition (wt%): Al:2.5~3.5; Zn:0.7~1.3; Mn:0.2~1.0; Mg:Remainder; Fe≤0.005; Si≤0.05; Cu≤0.05; Ni≤0.001
• Compliant Standards: GB/T 5153-2023, ASTM B90/B90M, EN 10204-3.1, RoHS 2.0
• Manufacturer: Huona New Material, certified to ISO 9001 and IATF 16949

Key Core Advantages (Centered on H112 Condition & Lightweight Design)

1. Ultra-Light & Stable Mechanical Properties

• Low Density: Density of only 1.77g/cm³ (1/4 of steel, 2/3 of aluminum), achieving maximum lightweight while maintaining excellent structural support.
• H112 Condition Benefits: Hot-rolled and stress-relieved, providing tensile strength ≥220MPa, yield strength ≥140MPa, and elongation ≥12%, with stable performance and minimal residual stress.

2. Good Formability & Processability

• Balanced Ductility: Elongation ≥12% in H112 condition, suitable for precision machining (turning/milling/drilling) and moderate forming operations.
• Machinability: Easy to machine with high surface finish, reducing processing time and cost.

3. Good Corrosion Resistance

• Natural Oxide Film: Dense magnesium oxide film formed on the surface, effectively resisting atmospheric and weak acid-base corrosion.
• Surface Treatment Compatibility: Supports anodizing, passivation, and painting for enhanced corrosion resistance in harsh environments.

4. Stable Microstructure & Performance

• Uniform Grain Structure: Precision rolling ensures consistent mechanical properties across the entire plate, reducing performance variability.
• Temperature Stability: Withstands service temperature from -40℃ to 150℃ (continuous), maintaining structural integrity without deformation.

5. Eco-Friendly & Sustainable

• 100% Recyclable: AZ31B magnesium alloy can be completely recycled and reused, with no heavy metal pollution, complying with green industrial development standards.

Technical Specifications

Product Specifications

Typical Application Scenarios

• Precision Machining Parts: Custom components for industrial machinery, automation equipment, and instrumentation.
• Automotive Lightweighting: Brackets, supports, and structural parts for electric vehicles and conventional automobiles.
• 3C Electronics: Precision frames and housings for laptops, tablets, and electronic devices.
• Aerospace & Rail Transit: Non-structural components for aircraft and train interiors.
• Industrial Equipment: Lightweight structural supports and custom parts for machinery.
