Silver Coated Copper Wire for Electronics High Conductivity Stable Signal Transmission
Silver Coated Copper Wire for Electronics High Conductivity Stable Signal Transmission
Specifications
Brand Name :
Huona
Model Number :
Silver Plated Copper Wire
Certification :
ISO9001,SGS
Place of Origin :
CHINA
MOQ :
10--50KG
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
500tons per month
Delivery Time :
5-21days
Packaging Details :
Cartons/Wooden case
Product Name :
Silver Plated Copper Wire
Base Copper Purity :
≥99.95%
Silver Plating Thickness 1um-10um(customizable) :
1μm-10μm(customizable)
Tensile Strength :
280-380 MPa
Elongation :
≥18%
Operating Temperature :
65°C to 150°C
Description
Product Description​
Silver - Plated Copper Wire​
Product Overview​
Silver - plated copper wire combines copper’s high conductivity with silver’s superior electrical performance and corrosion resistance. The pure copper core provides a low - resistance base, while the silver plating enhances conductivity and protects against oxidation. It is widely used in high - frequency electronics, precision connectors, and aerospace wiring systems.​
Standard Designations​
  • Material Standards:​
  • Copper: Complies with ASTM B3 (electrolytic tough - pitch copper).​
  • Silver plating: Follows ASTM B700 (electrodeposited silver coatings).​
  • Electrical conductors: Meets IEC 60228 and MIL - STD - 1580 standards.​
Key Features​
  • Ultra - high conductivity: Enables minimal signal loss in high - frequency applications.​
  • Excellent corrosion resistance: Silver plating resists oxidation and chemical erosion.​
  • High - temperature stability: Maintains performance in elevated temperature environments.​
  • Good solderability: Facilitates reliable connections in precision assembly.​
  • Low contact resistance: Ensures stable electrical signal transmission.​
Technical Specifications​
​
Attribute​
Value​
Base Copper Purity​
≥99.95%​
Silver Plating Thickness​
1μm–10μm (customizable)​
Wire Diameters​
0.2mm, 0.3mm, 0.5mm, 0.8mm, 1.0mm, 1.2mm (customizable)​
Tensile Strength​
280–380 MPa​
Elongation​
≥18%​
Electrical Conductivity​
≥100% IACS​
Operating Temperature​
- 65°C to 150°C​



​
Chemical Composition (Typical, %)​
​
Component​
Content (%)​
Copper (Core)​
≥99.95​
Silver (Plating)​
≥99.9​
Trace Impurities​
≤0.05 (total)​



​
Product Specifications​
​
Item​
Specification​
Available Lengths​
50m, 100m, 300m, 500m, 1000m (customizable)​
Packaging​
Spooled on anti - static plastic spools; packed in sealed cartons​
Surface Finish​
Bright silver - plated (uniform coating)​
Breakdown Voltage​
≥500V (for 0.5mm diameter wire)​
OEM Support​
Custom plating thickness, diameters, and labeling available​



​
We also supply other high - performance plated copper wires, including gold - plated copper wire and palladium - plated copper wire. Free samples and detailed technical datasheets are available upon request. Custom specifications can be tailored to meet specific high - precision application requirements.​
