Specifications
Model NO. :
WIND-TIG
Transport Package :
Wooden Case
Specification :
Middle Size
Trademark :
Wind Automation
Origin :
China
HS Code :
8479811000
Production Capacity :
100 Sets/Year
Description
Low Duty Motor Stator TIG Welding Machine
Stator TIG Welding Machine Thor Series for Middle Size Energy Motor 100 Sets/Year
This TIG welding machine will auto perform clamping, welding, loosening, rotating process. Indexing system and Panasonic argon arc welding machine ensures the high quality of each single weld.

(1)Specifications
Power Supply AC 380V 50Hz
Air Pressure Supply ≥0.5MPa
Productivity 2s/slot
Indexing method Servo
Weight 800KG
Dimension 1400x750x1950mm


(2) Features
Fully automatic welding cycle after loading of the stator
Temperature control system monitors the temperature of the joint during welding
Automatic servo controlled indexing
Water cooling system prevents overheating
High quality level of the wire fusing process
Can be customized accordingly
Memory storage of welding and stator's parameters
User-friendly operator interface via touch screen LCD display

(3)Machine configuration
Mitsubishi PLC and servo motor
Weinview touch screen
Panasonic argon arc welding machine
AIRTAC or SMC pneumatic components
HIWIN linear guide
Schneider electrical components

(4)TIG Welding Machine advantage

Comparing resistance welding, below are the reason why TIG welding are widely used in Hybrid car stator

1. The three conductor is not easy to clamp if use resistance welding

2. TIG welding is a kind of melting welding which have stronger connection of copper wire and copper wire,

3. Welding contacting resistance of TIG welding is smaller than resistance welding

4. All the three conductor's position are towards up in same way, it is easy to use TIG welding method,

Related pure electrical car also use TIG welding method
