10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard
Specifications
Brand Name :
HUATEC
Model Number :
HG-6500 Series
Certification :
ISO,CE
Place of Origin :
China
MOQ :
1pc
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100 pcs per month
Delivery Time :
3~7 days after payment
Packaging Details :
in carton
Product name :
Pocket Vibration Meter
Frequency range :
5Hz-10KHz
Function :
Acceleration, Velocity, Displacement, Temperature
Sensor type :
Low frequency and temperature (separate sensor)
Description

10Hz~1kHz Pocket Vibratioin (Temperature) Meter HG-6500 Series ISO2372 Standard


Features

• New technology design, low power consumption.
• Fully produced as international standard 1S02372, can directly determine the current state (well, pay attention or dangerous, etc.) of the machinery equipment
• High reliability rotary shear acceleration sensor has much better performance than compression sensor
• High and low frequency model, easy to recognize machinery fault
• Equip with signal input function, can test temperature with special temp sensor
• Equip with signal output function, can be connected with earphone, oscilloscope and vibration recording meter etc.
• In-built vibration sensor and separate sensor optional
• Can test vibration and temperature for all machinery equipment (fans, pumps, compressors, motors, etc.)
• The measurement value is automatically maintained
• Automatic shut down

Specifications
Sensors Rotary shear accelerometer
Split charge amplifier built-in shear accelerometer
Range Acceleration 0.1 ~199.9m/s2 (single peak) (5 or 10~1 KHz; 1 K~1 OKHz) Speed of 0.1 ~ 199.9mm/s (RMS) (5 or 10~1 KHz)
Displacement of 0.001 ~1.999mm (peak) (5 or 10~1 KHz) Temperature 0°C~400°C
Accuracy 5%士2 vibration words Temperature 1 %士1 word
Display LCD display 3 1/2 digits
Signal Output AC 2V peak (full scale and the load is greater than 1 OK ohms)
Power 9V laminated battery, can be used continuously 25 hours
Body volume 185mm x 68mm x 30mm
Weight 200g
