50-180kv Portable NDT Radiography Equipment For Industrial Radiographic Testing
50-180kv Portable NDT Radiography Equipment For Industrial Radiographic Testing
Specifications
Brand Name :
HUIWEI
Model Number :
RD-1803T
Certification :
ISO 9001, CE
Place of Origin :
ZHEJIANG, CHINA
MOQ :
1 set
Price :
6000usd/set
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
500sets within one month
Delivery Time :
15working days
Packaging Details :
Standard export plywood package
Film type :
Any kinds of industrial film
Voltage :
50-180kv
Exposure time :
5 minutes
Name :
NDT industrial x-ray machine
Tube current :
3mA
ControllerWeight :
12kg
Focus Spot :
0.9*0.9
Generator Weight :
12kg
Storage Temperature :
-20°C to 60°C
Focal Spot Size :
0.8 mm
Weight :
Less than 20 kg
Image Receptor :
Digital Detector Array (DDA)
Power Source :
Battery or AC Power
Dimensions :
40 cm x 30 cm x 20 cm
Maximum Output Current :
10 mA
Type :
Portable X-ray System
Operating Temperature :
0°C to 40°C
Maximum Output Voltage :
100 kV
Description

PRODUCT DESCRIPTION

Factory Price High Precision Portable Radiographic Testing (RT) Portable Industrial X-ray Machine RD-1803TH

Main introduction:

We are professinoal production of ceramic X ray tube.We can design and manufacture of various specification of X ray ceramic tube according to customer demands.
RD - 1803 represents a cutting - edge industrial X - ray device featuring an innovative design philosophy. This product boasts a compact size, lightweight build, along with reliability and durability. It has a rational internal structure and for the first time employs imported high - power components, equipped with a robust system protection function. It is applicable to power plants, chemical plants, aircraft manufacturing plants, boiler and pressure vessel manufacturing, aluminum tubes, aluminum sheets, and other scenarios, suitable for installation, maintenance, and non - destructive testing in confined spaces. The equipment is highly portable, with the generator weighing merely 12kg and an exquisite design. This series of equipment is categorized into directional and circumferential types, having a radiation angle of 40±5° and 360° respectively, and the maximum penetration thickness for A3 steel is 20mm.

Speed control to achieve the slow starting and low-speed positioning,magnetic position system tell the crawler's position and status through the beep sound .
Performing without affected by the electric welding machine.
Constant voltage control ensure X-ray film density consistent ,not impacted by low energy also save energy and protect the motor from over current.

RD-1803TH the technical parameters

Project

RD-1803TH

input

Input power

Single-phase 50Hz AC 220± 10% V

Power supply capacity

No less than 2.0 KVA

output

X - ray tube voltage

50~ 180 KVp

X ray tube current

3mA

mA Stability degree

± 1%

Ray tube

Focal size

1.0× 2.0

X-ray irradiation range

360°

Ray generator

working pressure

Cooling mode

Insulation way

0.45MPa ~ 0.5Mpa

Anode ground connection radiator Strong wind cold

Gas insulation SF6

Size

weight (kg)

Φ210×590

12

Maximum penetration

Thickness steel A3(mm)

20 mm (5 min)

condition

focal distance 600mm ,Agfa film,Double lead foil,Liquid temperature 22,Film density ≥1.5

sensitivity

superior 2%

controller

Size

weight

Circuit

325×270×180

< 9(kg)

Automatic control and protection

Environment

working temperature relative humidity

Altitude

-30°~ +40°

Not more than 85%

Not higher 1500m

methods

fully automatic 1:1 Work and rest,Longest continuous exposure time 5mins

FAQ

1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

2. why should you buy from us not from other suppliers?
HANGZHOU HUIWEI NDT DEVICES CO.,LTD is a professional manufacturer specilizing in NDT equipment for 30 years long, integrating development and manufacturing in-house. and it is one of companies strong supported by country.

3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C,Credit Card,Western Union,Escrow;
