Portable Panoramic X-Ray Flaw Detector Non Destructive Weld Testing Equipment RD-T200
Portable Panoramic X-Ray Flaw Detector Non Destructive Weld Testing Equipment RD-T200
Specifications
Brand Name :
HUIWEI
Model Number :
RD-T200
Certification :
ISO 9001, CE
Place of Origin :
ZHEJIANG, CHINA
MOQ :
1 set
Price :
24000-25000usd/set
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
500sets within one month
Delivery Time :
15working days
Packaging Details :
Standard export plywood package
Warranty :
12 Months
Usage :
spaceflight industry, welding engineering industry, shipbuilding industry inspection
Power supply :
AC220V±10%
Application :
Industrial field
Function :
steel defect,NDT inspection welding
Color :
Stainless Steel,Silver gray,blue and white
Max.penetration :
25mm(A3 STEEL)
Film type :
Any kinds of industrial film
Voltage :
100-200kv
Exposure time :
5 minutes
Name :
NDT industrial x-ray machine
Tube current :
3mA
Controller Weight :
12kg
Focus Spot :
1.5*1.5
Generator Weight :
15kg
Description

Portable Panoramic X-Ray Flaw Detector Non Destructive Weld Testing Equipment RD-T200

X Ray NDT Equipment/ NDT Radiographic Testing/NDT Flaw Inspection

NDT radiographic testing is a nondestructive testing (NDT)that uses x ray to examine the internal structure of some materials. The term NDT stands for non-destructive testing. This type of testing is often used in the manufacturing and aerospace industries. NDT X-ray testing can be used to detect a variety of different flaws, including cracks, porosity, and inclusions.


Applications
Welding inspection, internal defect detection in pipelines, and quality control for lightweight metals (e.g., aluminum alloys).

- Aerospace Industry: inspects weld seams and material integrity in aircraft components.
- Oil & Gas: Detects welding defects in pipelines and storage tanks.
- Automotive Manufacturing: Identifies internal flaws in vehicle components.
- Power Industry: Examines equipment in nuclear and power plants.

RD-T200 the technical parameters

Item RD-T200
Input Input power AC220V± 10% 50Hz
Power capacity Not less than 2.0 KVA
Output X-ray tube voltage 100~ 200 KVp
X-ray tube current 3mA
mA stability ± 1%
Ray tube Focus size (mm) 1.5× 1.5
Radiation angle 45±5°
Radiation generator

Working pressure

Cooling method

Insulation method

0.45MPa ~ 0.5Mpa

Anode grounded radiator, strong air cooling

Gas insulation SF6

Dimensions

Weight (kg)

 Φ200mm´635mm(Including end rings)
15
Maximum penetration Thickness Steel A3 (mm) 25(5min)
Conditions Focal length 600mm, Agfa film, double-sided lead foil sensitization, solution temperature 22 degrees, film blackness ≥ 1.5
Sensitivity Better than 2%
Controller

Dimensions

Weight

Circuit

350mm×265mm×200mm

< 8(kg)

Automatic control and protection
Environment

Operating temperature

Relative humidity

Altitude

-30°~ +40°

No more than 85%

No more than 1500 meters
Method Fully automatic 1:1 mode of work and rest, the longest continuous exposure time is 5 minutes

Portable Panoramic X-Ray Flaw Detector Non Destructive Weld Testing Equipment RD-T200

FAQ

1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

2. why should you buy from us not from other suppliers?
HANGZHOU HUIWEI NDT DEVICES CO.,LTD is a professional manufacturer specilizing in NDT equipment for 30 years long, integrating development and manufacturing in-house. and it is one of companies strong supported by country.

3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C,Credit Card,Western Union,Escrow;
