Low MOQ Custom PCB Service Lead-Free & Halogen-Free Best for DIY Makers & Startups
Low MOQ Custom PCB Service Lead-Free & Halogen-Free Best for DIY Makers & Startups
Specifications
Brand Name :
Xingqiang
Model Number :
As Per Customer's Model
Place Of Origin :
China
Certification :
ROHS,ISO,UL,IATF
MOQ :
Sample,1 Pc(5 Square Meters)
Price :
NA
Packaging Details :
Carton Or As Your Request
Delivery Time :
NA
Payment Terms :
,T/T,Western Union
Supply Ability :
100000㎡/Month
PCB Name :
Custom Multilayer PCB Board
AOI Testing :
Yes
Minimum Drill Size :
0.10mm
Minimumlinepacing :
3 Mil (0.075mm)
Board Thickness :
0.2-5.0Mm
Normal Count Layer :
2/4/6/8/10layers
Numberoflayers :
1 To 30+ Layers
Solder Mask :
Green or As Your Request
Hole Size Tolerance :
PTH ±0.075, NTPH ±0.05
Quotation Document :
Gerber Files or BOM List(PCBA)
Type :
Customizable pcb,Multilayer Board
Description

Reliable FR4 Multilayer PCB with Glass Fiber Cloth Reinforcement:

The board incorporates a glass fiber cloth base as its reinforcement material, ensuring exceptional mechanical strength and thermal stability.Whether you are developing products that require the sophistication of a FR4 Multilayer PCB or comparing options within the spectrum of multilayer boards including the 6 Layer PCB Board, this product offers a compelling blend of quality, performance, and value.Choose the Multilayer PCB Board for your next project and experience the multilayer PCB technology combined with practical design features tailored to your needs.

Multilayer PCB vs. Other PCB Types: Key Advantages:


Feature/Parameter FR4 Multilayer PCB (Glass Fiber Cloth Base) Standard Double-Sided PCB Single-Sided PCB Low-Cost Generic Multilayer PCB
Mechanical Strength Excellent (glass fiber reinforcement resists bending/impact) Moderate Poor Moderate (no premium reinforcement)
Thermal Stability High (handles -40°C to 125°C, ideal for industrial use) Moderate Low Moderate (prone to thermal warping)
Signal Integrity Excellent (impedance control, reduced crosstalk) Moderate Poor Average (basic impedance control)
Design Flexibility High (supports complex layouts, up to 16 layers) Moderate Very Low Moderate (limited layer count options)
Long-Term Reliability High (resists environmental stress, RoHS compliant) Moderate Low Average (lower-quality materials)
Best For Industrial controls, automotive electronics, 5G devices Consumer electronics, IoT sensors Simple toys, low-power devices Basic consumer electronics

End-to-End PCB Manufacturing Flow:
