HDI technology enables next-generation electronics by breaking space constraints while boosting electrical performance. As devices evolve toward smaller form factors with higher functionality, HDI PCBs provide the essential foundation for innovation in 5G, AI, IoT, and portable medical systems.
| Type | Structure | Typical Applications |
|---|---|---|
| 1-N-1 | 1 HDI layer sequence | Wearables, Basic IoT |
| 2-N-2 | 2 HDI layers per side | Smartphones, Tablets |
| Any-layer | Micro-vias on all layers | High-end CPUs, GPUs, 5G Modules |
| Full Layer Interconnect Structure | Every Layer Interconnect | Aerospace, Portable Medical Devices |
