Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike
Specifications
Supply Ability :
1000Unit/Month
Delivery Time :
5-12 weeks
Model Number :
E-KUP
Price :
Price negotiable
Packaging Details :
CKD,SKD,CBU
Payment Terms :
L/C,T/T
Place of Origin :
CHINA
MOQ :
20 Unit
Brand Name :
YIPOWER
Description

The whole vehicle is equipped with a high-end CAN bus intelligent communication system, realizing real-time data interaction among four core components: motor, controller, battery and instrument. Compared with traditional signal transmission, CAN communication features stronger anti-interference ability and more accurate and stable data transmission. It can real-timely monitor battery power, voltage, motor temperature and vehicle fault information. Matched with a high-definition LED intelligent instrument, all riding data is clear at a glance. It supports accurate fault self-inspection, greatly reducing vehicle failure rate, ensuring safer riding and more convenient maintenance.

Motor Type Permanent Magnet Synchronous Motor
Rated Power 1.5KW
Peak Power 4.8KW
Max Torque 166N·m
Transmission Mode Chain Drive
Communication CAN Communication
Controller FOC Vector Controller
Instrument LED Speedometer
Rated Voltage 60V
Dimensions (L×W×H) 1900mm×720mm×1080mm
Wheelbase 1260 mm
Ground Clearance 140 mm
Seat Height 770 mm
Tire Spec Front Tire: 2.50-17
Rear Tire: 2.75-17
Max Speed 45km/h
Max Climbing Angle ≥25°
Brake System Front Disc / Rear Drum
Battery Options 60V 30Ah Lithium Iron Phosphate Battery
60V 50Ah Ternary Lithium Battery
Lighting System LED
Dry Weight 80.5kg
Curb Weight 92.5kg
Max Load Capacity 150 kg
Driving Range (With 75kg rider) @25km/h 60V 30Ah LFP Battery: 95KM
60V 50Ah Ternary Battery: 158KM
Driving Range (With 75kg rider) @45km/h 60V 30Ah LFP Battery: 60km
60V 50Ah Ternary Battery: 100km

Custom motorcycle orders accepted
Wholesale from Factory

Send your message to this supplier
Send Now

Electric Underbone Motorcycle with CAN Bus Intelligent Communication System, 166N*m Max Torque and 158KM Max Mileage Commuter E-Bike

Ask Latest Price
Product Detail
Supply Ability :
1000Unit/Month
Delivery Time :
5-12 weeks
Model Number :
E-KUP
Price :
Price negotiable
Packaging Details :
CKD,SKD,CBU
Payment Terms :
L/C,T/T
