Diesel Particulate Filters For Exhaust System Diesel Particulate Filters
Diesel Particulate Filters For Exhaust System Diesel Particulate Filters
Diesel Particulate Filters For Exhaust System Diesel Particulate Filters
Diesel Particulate Filters For Exhaust System Diesel Particulate Filters
Specifications
Brand Name :
NKCHEM
Model Number :
NK-DPF
Certification :
SGS
Place of Origin :
Jiangxi, China
MOQ :
Diesel Particulate Filters for Exhaust System
Price :
CN¥1,820.99 - CN¥2,451.33
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, L/C, D/A
Supply Ability :
500 Metric Ton/Metric Tons per Month
Delivery Time :
5-8 work day
Packaging Details :
carton with pallet or carton with wooden case
Material :
cordierite , silicon carbide
Type :
Catalytic Converter
Shape :
Round, oval, racetrack or abnormity
Description

Diesel Particulate Filters For Exhaust System Diesel Particulate Filters - Range Of Direct Fit Dpf/Fap Available

Diesel Particulate Filters Introduction:

Diesel particulate filter is used to remove black smoke (PM e.g.: Hydrocarbons, soot) from diesel engine exhaust, being a great contribution to the environment because of dealing with the exhaust from diesel engines. The diesel particulate filter can be used in different industrial fields such as environment protection, petrol-chemistry, medicine manufacture, and metallurgy etc. It has good investment return and broad prospect. The system installed DPF (Diesel Particulate Filter) been examined for urban bus, forklift, truck & mining constructing equipment.Diesel Particulate Filters For Exhaust System Diesel Particulate Filters

Material Attributes:

Property (uncatalyzed) 100/17 200/12
Cell density cpsi 100 200
cpscm 15.5 31.0
Wall thickness inch 0.017 0.012
mm 0.432 0.305
Open frontal area (OFA), % 34.5 34.5
Geometric surface area (GSA) Inch2 33.3 47.0
m2/l 1.31 1.85
Hydraulic diameter Inch 0.083 0.059
mm 2.11 1.49
Modulus of rupture (psi/cpscm) 350 300
Porosity (%) 48 48

Coefficient of thermal expansion

102 cm/cm/ (20-800) --maximum average

 5 5
Mean pore size (micron) 13 13
Melting temperature () 1460 1460

Physical components

Component Unit Data Component Unit Data
SiO2 wt% 48-51 Fe2O3 wt% <0.5
Al2O3 wt% 31-34 Na2O wt% <0.5
MgO wt% 14-16 K2O wt% <0.5

Specifications:

100cpsi

NO. Item Our products
1 Filter material Cordierite and Silicon carbide
2 Operating temperature limit (0C) 1000
3 Dimension (mm) Ø144x150,Ø144x152.4,Ø150x150,Ø190x200,Ø190x203, Ø240x240,Ø240x305 Ø260x305, Ø267x305, Ø286x305, Ø286x355,Ø374x270x317
4 Cell pitch (mm) 100 cpsi
5 Cell wall thickness (mm) 0.45-0.52
6 Cell size (mm) 2.02-2.09
7 Mean pore size (um) 8-13
8 Porosity (gas pocket rate) % 50-55
9 Coefficient of thermal expansion 1.6x10-6
10 Softening temperature (0C) 1360
11 Compressive Strength (Mpa) Lengthwise direction 10
Lateral direction 2
12 Water absorption rate:

35%
