Specifications
Maximum Current :
100A
Enclosure :
Galvanized steel
OCPP :
OCPP 1.6 (OCPP 2.0 optional)
Cooling Method :
Fan cooling
Charge Connector :
CCS2/GBT/CCS1/CHAdemo
Start Mode :
Plug&Charge/RFID card/APP
Ethernet/3G/4G :
Optional
Package Dimension :
1070*960*600mm (L*W*H)
Certification :
CE/CB
Gross Weight :
111kg
Rated Power :
30kW
Emergency Stop :
Yes
Cable Length :
5M
LCD Display :
7 inch
WiFi :
Optional
Noise :
≤ 60dB
Work Altitude :
<2000m
Ingress Protection :
IP54
Work Humidity :
5%~95%
Model Number :
C Series
Price :
Negotiable
Rated Voltage :
AC400V
Energy Meter :
MID certified
Installation :
Wall-mount/Pole-mount
External Package :
Carton
Brand Name :
DOOR
MOQ :
1PC
Power Supply :
3P+N+PE
RCD :
Type A
LED Indicator :
Green/Blue/Red
Certification Standard :
EN/IEC 61851-1: 2017, EN/IEC 61851-23: 2014
Warranty :
2 years
Payment Terms :
L/C,T/T,Western Union
Frequency :
50/60Hz
Work Temperature :
-30℃ ~+50℃
Place of Origin :
China
Delivery Time :
30-45 days
Output Voltage :
DC 200~750V
Impact Protection :
IK08
Description

C Series Dc chargers


The C Series Dc chargers in 20kw, 30kw, and 40kw are specifically designed for hotels,resorts, high-end restaurants, golf clubs, and business parks. Certified, iP54 protected, and backed by a 2-year extendable warranty.

_______________________________________________________________________________________________________________

1.Medium Charging Speeds


Significantly reducing charging times compared to AC, tailored to match typical vehicle dwell times at destinations, helping improve usage turnover efficiency.


2.ldeal For Short & Medium Stays


Perfect for 1-4 hour parking scenarios like hotels, premium dining, and golf clubs where guests expect a fast, convenient top-up.


3.Premium Property Value


Elevate your brand by offering high-end, reliable EV charging amenities that attract affluent EV drivers and enhance customer satisfaction.


4.Smart Management


Advanced features including APP control, RFlD access,OCPP platform integration, and dynamic load balancing.
