Heavy Duty Steel Floor Prefabricated House Industrial Grade Light Steel Frame Workshop Garage Prefab Building Unit
Heavy Duty Steel Floor Prefabricated House Industrial Grade Light Steel Frame Workshop Garage Prefab Building Unit
Heavy Duty Steel Floor Prefabricated House Industrial Grade Light Steel Frame Workshop Garage Prefab Building Unit
Heavy Duty Steel Floor Prefabricated House Industrial Grade Light Steel Frame Workshop Garage Prefab Building Unit
Specifications
Certification :
CE, ISO 9001:2015
Packaging Details :
Heavy duty flat pack with steel floor panels separate, 2x 40HQ per unit
Electrical :
3-phase 15A
Price :
USD 8,500-14,000 / Set
Floor Coating :
1.5mm Epoxy
MOQ :
1 Set
Floor Load :
500kg/m²
Crane Capacity :
2-tonne Underslung
Column Steel :
4mm Wall Thickness
Roller Door :
3000x3000mm Electric
Floor :
5mm Checkered Steel Plate
Model Number :
PH-HD60W
Clear Span :
8000mm
Delivery Time :
15-25 working days after deposit
Brand Name :
ECONEL
Lighting :
4x 150W LED, 500 lux
Place of Origin :
Shandong, China
Structure Type :
Heavy Duty Industrial Prefab
Payment Terms :
T/T, L/C at sight
Supply Ability :
150 Sets per Month
Description

Heavy Duty Industrial Steel Floor Prefabricated House

This prefabricated container house combines industrial-grade durability with efficient modular design, delivering cost-effective building solutions for diverse project requirements worldwide.

Key Features

  • Industrial-grade steel floor system: 5mm checkered steel plate on C-section steel joists at 400mm centers, rated 500kg/m²
  • Reinforced light steel frame with 4mm wall thickness columns and portal frame design for 8000mm clear span without internal columns
  • Roller shutter door opening (3000x3000mm) with electric motor and remote control, plus separate personnel door
  • Overhead crane ready: reinforced roof truss with 2-tonne underslung hoist beam and 15A 3-phase power supply point
  • Epoxy floor coating (1.5mm, light grey) with chemical resistance to oils, solvents, and mild acids for workshop environments
  • High-bay LED lighting (150W, 15000 lumens each, 4 units) providing 500 lux at work surface for detailed tasks
  • Explosion-proof electrical certification option (ATEX Zone 2) for hazardous environment workshop applications

Technical Specifications

External Size10000x6000x4000mm
StructurePortal Frame Light Steel, 4mm Columns
Clear Span8000mm (no internal columns)
Floor System5mm Checkered Plate on C-Section Joist
Floor Load500kg/m² Live Load
Roller Door3000x3000mm Electric with Remote
Personnel Door900x2100mm Steel Security Door
Lighting4x 150W LED High-bay (500 lux)
Crane Ready2-tonne Underslung Beam + 3-phase Power
Floor Coating1.5mm Epoxy, Chemical Resistant

Applications

  • Vehicle maintenance workshops and garages
  • Light manufacturing and assembly facilities
  • Agricultural machinery and equipment storage
  • Warehouse and logistics distribution centers
  • Research laboratory and testing facility buildings

Factory prefabricated with strict quality control. CE, ISO 9001:2015, and SGS certified. Contact us for custom design and bulk order quotation.
