500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel
Specifications
Material Option :
SS304 / SS316L (Sanitary Grade)
Certification :
CE, ISO 9001
Product Feature :
Double-Layer Jacketed Mixing Tank with Agitator
Brand Name :
Vison Chemicals
Agitator Type :
Anchor + Scraper / Paddle (Configurable)
After-Sales Support :
Online Guidance, Video Inspection, On-Site Commissioning
MOQ :
1 Set (Sample Order Welcome)
Delivery Time :
30-45 Days (Expedited Available)
Surface Finish :
Mirror Polish, CIP Compatible
Payment Terms :
T/T 30% Advance, L/C at Sight
Heating Method :
Steam / Electric / Hot Water / Thermal Oil
Place of Origin :
Guangzhou, China
Insulation :
Rock Wool 50mm (Optional)
Price :
Custom Quote
Discharge Valve :
Bottom Ball Valve DN40, Sanitary Tri-Clamp
Supply Ability :
20+ Sets per Month
Jacket Type :
Full Outer Jacket — Even Heat Distribution
Model Number :
VH-DJ500
Warranty :
12 Months on Motor & Vessel
Packaging Details :
Export Plywood Case with Moisture Barrier
Description

500L Stainless Steel Mixing Tank with Heating Jacket — Double-Layer Temperature Controlled Vessel

Purpose-built for processes requiring precise temperature control. Outer jacket circulates steam, hot water, or thermal oil while the SS304/SS316L inner vessel holds your product. Ideal for heating, cooling, and temperature-sensitive formulations.

Heating Options

Method Temp Range Best For
Steam Jacket Up to 150°C Chemical reactions, sterilization
Electric Heating 30-200°C Precise control, no boiler needed
Hot Water 30-95°C Gentle heating, food/cosmetic
Thermal Oil Up to 250°C High-temp chemical processes

Technical Specifications

Parameter Specification
Model VH-DJ500
Capacity 500 Liters
Jacket Full outer double-layer
Material SS304 / SS316L (Sanitary)
Surface Mirror Polish, CIP Compatible
Agitator Anchor + scraper / paddle
Motor 2.2 / 3.0 / 4.0 kW, 0-85 RPM
Insulation Rock wool 50mm (optional)
Discharge Bottom ball valve DN40
Voltage 220V/380V/440V, 50/60Hz

Industries

Industry Application
Cosmetics Cream melting, lotion heating, wax blending
Food & Beverage Syrup heating, chocolate melting
Chemicals Resin heating, surfactant blending
Detergents Hot-mix detergent preparation
