Specifications
Brand Name :
TYHE
Model Number :
TJZ37FGb
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm
Voltage :
6V 12V 24V customized
Speed :
20-800rpm
Torque :
≤2.5N.m
Gear material :
Powder metallurgy, steel
Type :
Geared Motor
Usage :
Medical appliance
Keywords :
IE3 Steel Gear Micro 37mm Rs545 Brushed 24v 500rpm 0.5N.m Dc Gear Reduction Motor Ce Rohs
Color :
Silver
Description

Products Description

IE3 Steel Gear Micro 37mm Rs545 Brushed 24v 500rpm 0.5N.M Dc Gear Reduction Motor Ce Rohs

2D drawing

Ie3 Steel Gear Micro 37mm Rs545 Brushed 24v 500rpm 0.5n.M Dc Gear Reduction Motor Ce Rohs

Model End cover dimensions Motor type Regular Shaft Weight
TJZ37FGb 40*40mm RS545 6mm-D cut 300g


Ie3 Steel Gear Micro 37mm Rs545 Brushed 24v 500rpm 0.5n.M Dc Gear Reduction Motor Ce Rohs

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
RS545 6 3200 280 2560 0.81 11.20 3.00 61.65 33.60 4.70
RS545 12 2000 70 1600 0.20 8.95 1.50 63.54 26.85 1.10
RS545 24 6000 160 4800 0.60 17.50 8.80 61.25 52.50 4.30
RS545 24 8300 200 6640 0.88 19.30 13.42 63.90 57.90 6.90
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 6V-3200RPM Input 12V-2000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 556.5 2.43 41.73 125.19 347.8 1.21 33.35 100.04
22.5 81 5.9 433.9 2.43 53.52 160.57 271.2 1.21 42.77 128.32
22.5 73 8.4 304.8 2.19 68.68 206.04 190.5 1.09 54.88 164.64
22.5 73 10.6 241.5 2.19 86.67 260.00 150.9 1.09 69.26 207.77
22.5 73 13.5 189.6 2.19 110.38 331.13 118.5 1.09 88.20 264.61
24.5 65.6 19.3 132.6 1.97 141.80 425.40 82.9 0.98 113.31 339.94
24.5 65.6 24.4 104.9 1.97 179.27 537.82 65.6 0.98 143.26 429.77
24.5 65.6 31.6 81.0 1.97 232.17 696.51 50.6 0.98 185.53 556.59
26.5 59 45.0 56.9 1.77 297.36 892.08 35.6 0.88 237.62 712.87
26.5 59 57.0 44.9 1.77 376.66 1129.97 28.1 0.88 300.99 902.97
26.5 59 73.6 34.8 1.77 486.35 1459.05 21.7 0.88 388.64 1165.93
29.5 53 105.0 24.4 1.59 623.28 1869.84 15.2 0.79 498.07 1494.20
29.5 53 133.0 19.2 1.59 789.49 2368.46 12.0 0.79 630.89 1892.66
29.5 53 172.0 14.9 1.59 1020.99 2500.00 9.3 0.79 815.88 2447.65
32.5 47.8 245.0 10.4 1.44 1311.63 2500.00 6.5 0.72 1048.13 2500.00
32.5 47.8 310.0 8.3 1.44 1659.62 2500.00 5.2 0.72 1326.21 2500.00
32.5 47.8 401.0 6.4 1.44 2146.79 2500.00 4.0 0.72 1715.52 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-6000RPM Input 24V-8300RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 1043.5 7.12 65.21 195.62 1443.5 10.87 71.91 215.74
22.5 81 5.9 813.6 7.12 83.63 250.90 1125.4 10.87 92.23 276.70
22.5 73 8.4 571.4 6.42 107.31 321.93 790.5 9.80 118.35 355.04
22.5 73 10.6 452.8 6.42 135.42 406.25 626.4 9.80 149.34 448.03
22.5 73 13.5 355.6 6.42 172.46 517.39 491.9 9.80 190.20 570.60
24.5 65.6 19.3 248.7 5.77 221.56 664.69 344.0 8.80 244.35 733.06
24.5 65.6 24.4 196.7 5.77 280.11 840.34 272.1 8.80 308.92 926.77
24.5 65.6 31.6 151.9 5.77 362.77 1088.30 210.1 8.80 400.08 1200.24
26.5 59 45.0 106.7 5.19 464.63 1393.88 147.6 7.92 512.42 1537.25
26.5 59 57.0 84.2 5.19 588.53 1765.58 116.5 7.92 649.06 1947.18
26.5 59 73.6 65.2 5.19 759.92 2279.76 90.2 7.92 838.08 2500.00
29.5 53 105.0 45.7 4.66 973.88 2500.00 63.2 7.11 1074.05 2500.00
29.5 53 133.0 36.1 4.66 1233.58 2500.00 49.9 7.11 1360.46 2500.00
29.5 53 172.0 27.9 4.66 1595.30 2500.00 38.6 7.11 1759.39 2500.00
32.5 47.8 245.0 19.6 4.20 2049.43 2500.00 27.1 6.41 2260.22 2500.00
32.5 47.8 310.0 15.5 4.20 2500.00 2500.00 21.4 6.41 2500.00 2500.00
32.5 47.8 401.0 12.0 4.20 2500.00 2500.00 16.6 6.41 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.

Company Profile

WenZhou TYHE Motor Co.,ltd. was established in May, 2010 and is located in WenZhou, China. TYHE covers an area of 3500㎡. And we have excellent teams who focus on R&D, QC and company operation.

  1. 11 years experiences in dc gear motor industry.
  2. Accept OEM or ODM orders.
  3. 5 days lead time for samples.
  4. Monthly capacity is ≥500000pcs.
  5. Warranty: one year.
  6. 10 R&D engineers offer professional solutions.
  7. Fast delivery time base on different quantities.
  8. CE, ROHS and ISO9001 certificated.
