Specifications
Brand Name :
TYHE
Model Number :
TJP37RM
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm size
Voltage :
6V 12V 24V customized
Speed :
80rpm 100rpm 160rpm or Customized
Torque :
1.5N.m
Gear material :
Powder metallurgy, steel
Commutation :
Brush brushes brushed
Type :
Gear Motor, Micro Motor
Usage :
Electraflow
Keywords :
Electraflow 37mm Rs395 12v 85rpm Big Torque Small Brushed Dc Gear Motor Ce Rohs
Description

Products Description

Electraflow 37mm Rs395 12v 85rpm Big Torque Small Brushed Dc Gear Motor Ce Rohs

2D drawing

Electraflow 12V 85rpm Small Gear Motor High Torque RS395 CE ROHS


Electraflow 12V 85rpm Small Gear Motor High Torque RS395 CE ROHS

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY2847 12 4500 100 3600 0.30 5.89 2.22 61.68 17.67 1.70
ZY2847 12 7500 160 6000 0.60 7.17 4.50 62.57 21.51 4.80
ZY2847 24 5000 50 4000 0.20 7.25 3.04 63.26 21.75 1.14
ZY2847 24 7500 75 6000 0.28 6.64 4.17 62.08 19.92 1.70
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-4500RPM Input 12V-7500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 6.5 553.8 1.80 31.01 93.03 923.1 3.65 37.75 113.25
22.5 81 7.6 473.7 1.80 36.26 108.78 789.5 3.65 44.14 132.42
22.5 73 9.3 387.1 1.62 39.99 119.96 645.2 3.29 48.68 146.03
22.5 73 11.8 305.1 1.62 50.74 152.21 508.5 3.29 61.76 185.29
22.5 73 15.2 236.8 1.62 65.36 196.07 394.7 3.29 79.56 238.67
22.5 73 20.4 176.5 1.62 87.71 263.14 294.1 3.29 106.78 320.33
24.5 65.6 27.5 130.9 1.46 106.26 318.77 218.2 2.96 129.35 388.04
24.5 65.6 35.6 101.1 1.46 137.55 412.66 168.5 2.96 167.45 502.34
24.5 65.6 41.6 86.5 1.46 160.74 482.21 144.2 2.96 195.67 587.00
24.5 65.6 57.7 62.4 1.46 222.94 668.83 104.0 2.96 271.39 814.18
26.5 59 73.4 49.0 1.31 255.07 765.22 81.7 2.66 310.50 931.51
26.5 59 83 43.4 1.31 288.43 865.30 72.3 2.66 351.11 1053.34
26.5 59 97 37.1 1.31 337.08 1011.25 61.9 2.66 410.34 1231.02
26.5 59 111 32.4 1.31 385.74 1157.21 54.1 2.66 469.56 1408.69
26.5 59 119 30.3 1.31 413.54 1240.61 50.4 2.66 503.41 1510.22
26.5 59 130 27.7 1.31 451.76 1355.29 46.2 2.66 549.94 1649.82
29.5 53 194 18.6 1.18 605.61 1816.83 30.9 2.39 737.22 2211.66
29.5 53 226 15.9 1.18 705.50 2116.51 26.5 2.39 858.82 2500.00
29.5 53 259 13.9 1.18 808.52 2425.56 23.2 2.39 984.23 2500.00
29.5 53 277 13.0 1.18 864.71 2500.00 21.7 2.39 1052.63 2500.00
29.5 53 303 11.9 1.18 945.88 2500.00 19.8 2.39 1151.43 2500.00
29.5 53 316 11.4 1.18 986.46 2500.00 19.0 2.39 1200.83 2500.00
29.5 53 346 10.4 1.18 1080.11 2500.00 17.3 2.39 1314.83 2500.00
29.5 53 382 9.4 1.18 1192.49 2500.00 15.7 2.39 1451.64 2500.00
32.5 47.8 452 8.0 1.06 1272.57 2500.00 13.3 2.15 1549.12 2500.00
32.5 47.8 528 6.8 1.06 1486.54 2500.00 11.4 2.15 1809.59 2500.00
32.5 47.8 604 6.0 1.06 1700.51 2500.00 9.9 2.15 2070.07 2500.00
32.5 47.8 665 5.4 1.06 1872.25 2500.00 9.0 2.15 2279.13 2500.00
32.5 47.8 733 4.9 1.06 2063.70 2500.00 8.2 2.15 2500.00 2500.00
32.5 47.8 808 4.5 1.06 2274.86 2500.00 7.4 2.15 2500.00 2500.00
32.5 47.8 890 4.0 1.06 2500.00 2500.00 6.7 2.15 2500.00 2500.00
32.5 43 1232 2.9 0.95 2500.00 2500.00 4.9 1.94 2500.00 2500.00
32.5 43 1408 2.6 0.95 2500.00 2500.00 4.3 1.94 2500.00 2500.00
32.5 43 1552 2.3 0.95 2500.00 2500.00 3.9 1.94 2500.00 2500.00
32.5 43 1711 2.1 0.95 2500.00 2500.00 3.5 1.94 2500.00 2500.00
32.5 43 2077 1.7 0.95 2500.00 2500.00 2.9 1.94 2500.00 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-5000RPM Input 24V-7500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 6.5 615.4 2.46 38.17 114.51 923.1 3.38 34.96 104.88
22.5 81 7.6 526.3 2.46 44.63 133.89 789.5 3.38 40.88 122.63
22.5 73 9.3 430.1 2.22 49.22 147.66 645.2 3.05 45.08 135.24
22.5 73 11.8 339.0 2.22 62.45 187.35 508.5 3.05 57.20 171.59
22.5 73 15.2 263.2 2.22 80.45 241.34 394.7 3.05 73.68 221.03
22.5 73 20.4 196.1 2.22 107.97 323.90 294.1 3.05 98.88 296.65
24.5 65.6 27.5 145.5 1.99 130.79 392.37 218.2 2.74 119.79 359.36
24.5 65.6 35.6 112.4 1.99 169.31 507.94 168.5 2.74 155.07 465.20
24.5 65.6 41.6 96.2 1.99 197.85 593.55 144.2 2.74 181.20 543.61
24.5 65.6 57.7 69.3 1.99 274.42 823.26 104.0 2.74 251.33 754.00
26.5 59 73.4 54.5 1.79 313.97 941.91 81.7 2.46 287.55 862.66
26.5 59 83 48.2 1.79 355.03 1065.10 72.3 2.46 325.16 975.48
26.5 59 97 41.2 1.79 414.92 1244.75 61.9 2.46 380.01 1140.02
26.5 59 111 36.0 1.79 474.80 1424.41 54.1 2.46 434.85 1304.56
26.5 59 119 33.6 1.79 509.02 1527.07 50.4 2.46 466.19 1398.58
26.5 59 130 30.8 1.79 556.08 1668.23 46.2 2.46 509.29 1527.86
29.5 53 194 20.6 1.61 745.45 2236.34 30.9 2.21 682.72 2048.17
29.5 53 226 17.7 1.61 868.41 2500.00 26.5 2.21 795.34 2386.02
29.5 53 259 15.4 1.61 995.21 2500.00 23.2 2.21 911.47 2500.00
29.5 53 277 14.4 1.61 1064.37 2500.00 21.7 2.21 974.82 2500.00
29.5 53 303 13.2 1.61 1164.28 2500.00 19.8 2.21 1066.32 2500.00
29.5 53 316 12.7 1.61 1214.23 2500.00 19.0 2.21 1112.07 2500.00
29.5 53 346 11.6 1.61 1329.51 2500.00 17.3 2.21 1217.64 2500.00
29.5 53 382 10.5 1.61 1467.84 2500.00 15.7 2.21 1344.33 2500.00
32.5 47.8 452 8.8 1.45 1566.41 2500.00 13.3 1.99 1434.61 2500.00
32.5 47.8 528 7.6 1.45 1829.78 2500.00 11.4 1.99 1675.83 2500.00
32.5 47.8 604 6.6 1.45 2093.16 2500.00 9.9 1.99 1917.05 2500.00
32.5 47.8 665 6.0 1.45 2304.56 2500.00 9.0 1.99 2110.66 2500.00
32.5 47.8 733 5.5 1.45 2500.00 2500.00 8.2 1.99 2326.48 2500.00
32.5 47.8 808 5.0 1.45 2500.00 2500.00 7.4 1.99 2500.00 2500.00
32.5 47.8 890 4.5 1.45 2500.00 2500.00 6.7 1.99 2500.00 2500.00
32.5 43 1232 3.2 1.31 2500.00 2500.00 4.9 1.79 2500.00 2500.00
32.5 43 1408 2.8 1.31 2500.00 2500.00 4.3 1.79 2500.00 2500.00
32.5 43 1552 2.6 1.31 2500.00 2500.00 3.9 1.79 2500.00 2500.00
32.5 43 1711 2.3 1.31 2500.00 2500.00 3.5 1.79 2500.00 2500.00
32.5 43 2077 1.9 1.31 2500.00 2500.00 2.9 1.79 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.
