New Type Water Oil Steam Pipe Multiport Filter ASME B16.5 JISB titanium Pipe Fitting Valves Flanges
| Chemical requirements |
| N | C | H | Fe | O | Al | V | Pd | Mo | Ni | Ti |
| Gr1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | / | / | / | / | / | bal |
| Gr2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | / | / | bal |
| Gr5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| Gr7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
| Tensile requirements |
| Grade | Tensile srength(min) | Yeild strength(mm) | Elongation(%) |
| KSI | MPa | Ksi | MPa |
|
| 1 | 35 | 240 | 20 | 138 | 24 |
| 2 | 50 | 345 | 40 | 275 | 20 |
| 5 | 130 | 895 | 120 | 828 | 10 |
| 7 | 50 | 345 | 40 | 275 | 20 |
| 12 | 70 | 438 | 50 | 345 | 18 |
Material Grade: Gr1, Gr1, Gr2, Gr3, Gr4, Gr7, Gr9
Standard: ANSI B16.5,JIS B2220, DIN2627-2628,ASME,GB/T 9116, ASTM B16.5.
Technique: Forged and CNC Machined.
Type: WN , SO , BL ,SW, PL, Lap joint, customized.
Application: used in cars, glasses,medical equipment , electronics , petrochemical equ ipment,Pump valve, pipeline, aerospace,Ocean Industry,etc.
Advantage: Long service life, corrosion -resistant, hign yeiled strenth and tensile strength. | size | 1/2"~ 30"NB, NPS 1/2 - NPS 24 (DN 10 - 2000) |
| Pressure Class | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64, etc/ |
| Flange Face Type | Flat Face(FF), Raised Face(RF), Ring Type Joint(RTJ) |
| Grade | Titanium Gr1, Titanium Gr2, Titanium Gr4, Titanium Gr5, Titanium Gr7 |
| Available Dimensions | OD:200-1300mm ID:100-900mm Height:35-250mm |
