ASTM B16.5 Titanium Socket Weld (SW) Flange | RF Facing | Polished Surface
ASTM B16.5 Titanium Socket Weld (SW) Flange | RF Facing | Polished Surface
ASTM B16.5 Titanium Socket Weld (SW) Flange | RF Facing | Polished Surface
ASTM B16.5 Titanium Socket Weld (SW) Flange | RF Facing | Polished Surface
Specifications
Brand Name :
LH-Ti
Model Number :
LH-BL
Certification :
ISO9001, TUV etc.
Place of Origin :
Baoji, China
MOQ :
1 piece
Price :
US dollar $30/pc--US dollar $80/pc
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
5000 pcs per month
Delivery Time :
3-15 work days
Packaging Details :
Wrapped by foam contained in plywood box for export
Commodity :
Flat welded flange /welding plate flange
Type :
Weld Neck, Slip On, Blind, Threaded, Lap Joint
Application :
Chemical, Petrochemical, Marine, Aerospace
Technics :
Forged and CNC Machined
Unit Price :
$25usd/pc-$85usd/pc
Item Name :
titanium weld neck flange
Temperaturerange :
-200°C to 600°C
Din :
PN6,PN10,PN16,PN25 though PN250
Description
ASTM B16.5 Titanium Socket Weld (SW) Flange | RF Facing | Polished Surface
High-Precision Polished Titanium Socket Weld Flanges

Our Titanium Socket Weld (SW) Flanges are the premier choice for small-diameter, high-pressure piping systems. Unlike slip-on flanges, the socket weld design provides a smooth bore and better flow characteristics, reducing turbulence and erosion inside the joint.

ASTM B16.5 Titanium Socket Weld (SW) Flange | RF Facing | Polished Surface
Item Specification
Type Socket Weld (SW) Flange / Sleeve Welding
Material Grade 2, Grade 5, Grade 7 (Palladium-enhanced)
Facing Raised Face (RF) - Serrated or Smooth Finish
Standard ASME B16.5, ANSI, DIN 2633
Surface Finish Mirror Polished (Ra < 0.2μm) or Bright Annealed
Size Range 1/2" to 3" (Ideal for small-bore high-pressure piping)
Application Critical chemical lines, high-purity gas systems
Why Polished Surface Matters?

The mirror-polished surface (Ra < 0.2μm) is not just for aesthetics. In industries like semi-conductor processing and specialty chemicals:

  • Contamination Control: A polished surface prevents particle entrapment and makes cleaning/sterilization more effective.
  • Enhanced Corrosion Resistance: Polishing removes surface imperfections where stress corrosion cracking could potentially start.
ASTM B16.5 Titanium Socket Weld (SW) Flange | RF Facing | Polished SurfaceAdvanced Machining & Fitment

Each flange undergoes rigorous CNC machining to ensure the socket depth and diameter perfectly match your titanium piping. This ensures a tight fit-up and a high-quality fillet weld, minimizing the risk of weld leakage in critical environments.

FAQ:

Q: What is the main advantage of a Socket Weld Flange over a Slip-On Flange?
A: Socket weld flanges have an internal recessed area that acts as a guide for the pipe, providing a smoother internal flow and higher fatigue strength than slip-on flanges.

Q: Can I get these flanges with a customized RF height?
A: Yes. While 1/16" (1.6mm) is the standard RF height for Class 150/300, we can customize the facing dimensions according to your specific gasket and sealing requirements.
