Ruggedized Handheld Radios for Dynamic Ad Hoc Networking
Ruggedized Handheld Radios for Dynamic Ad Hoc Networking
Ruggedized Handheld Radios for Dynamic Ad Hoc Networking
Ruggedized Handheld Radios for Dynamic Ad Hoc Networking
Specifications
Net Device Dimensions :
≤225 × 90 × 50mm
Delivery Time :
Negotiable
Frequency Range :
UHF、L、S, Customizable
Certification :
CE
Brand Name :
hanxun
Price :
Negotiable
Net Device Weight :
≤1.2 kg
MOQ :
2
Payment Terms :
T/T,L/C
Bandwidth :
5、10、20MHz
Interface :
Serial port, Ethernet port, power interface, RF interface
Description

Product Introduction


Featuring a 2×2 MIMO dual-antenna system and 4W transmit power, this handheld unit delivers high-performance Layer 2 transparent data transmission. It is engineered to support complex IP-based multimedia services, including real-time video and voice, within a distributed MANET environment.


Wideband Communication
Supports wideband communication in the 1420–1520 MHz frequency band, effectively adapting to complex terrain environments, and provides customizable frequency bands.
Intelligent Frequency Selection
Supports intelligent frequency selection, with adjustable bandwidths of 5/10/20 MHz.
HD Display
Equipped with a display screen for viewing device status, link status, straight-line distance to nodes, etc. Quick configuration can be performed via on-screen buttons.
Battery Indicator
Features a touch-activated battery display; a light touch shows the current battery level.



Specifications


Encryption Support software encryption
Power Supply Battery-powered, DC external power supply
Modulation BPSK/QPSK/16QAM/64QAM,dynamic self-adapting
Networking capability 32 nodes, support customization
MIMO Mode 2T2R
Network port 100-megabit data network port
Other functions Time Division multiplexing, frequency division multiplexing, beam forming, MIMO
