Deployable Self-Forming Mesh Communication Handsets
Deployable Self-Forming Mesh Communication Handsets
Deployable Self-Forming Mesh Communication Handsets
Deployable Self-Forming Mesh Communication Handsets
Deployable Self-Forming Mesh Communication Handsets
Deployable Self-Forming Mesh Communication Handsets
Specifications
Delivery Time :
Negotiable
MOQ :
2
Certification :
CE
Net Device Dimensions :
≤225 × 90 × 50mm
Net Device Weight :
≤1.2 kg
Brand Name :
hanxun
Price :
Negotiable
Frequency Range :
UHF、L、S, Customizable
Payment Terms :
T/T,L/C
Interface :
Serial port, Ethernet port, power interface, RF interface
Bandwidth :
5、10、20MHz
Description

Product Introduction


Despite its compact form factor, this radio offers powerful communication capabilities. It supports 4W transmit power and a 2×2 MIMO system, providing a reliable, transparent channel for video, voice, and data in a portable, handheld design suitable for mobile ad hoc networking.


Wideband Communication
Supports wideband communication in the 1420–1520 MHz frequency band, effectively adapting to complex terrain environments, and provides customizable frequency bands.
Intelligent Frequency Selection
Supports intelligent frequency selection, with adjustable bandwidths of 5/10/20 MHz.
HD Display
Equipped with a display screen for viewing device status, link status, straight-line distance to nodes, etc. Quick configuration can be performed via on-screen buttons.
Battery Indicator
Features a touch-activated battery display; a light touch shows the current battery level.



Specifications


Encryption Support software encryption
Power Supply Battery-powered, DC external power supply
Modulation BPSK/QPSK/16QAM/64QAM,dynamic self-adapting
Networking capability 32 nodes, support customization
MIMO Mode 2T2R
Network port 100-megabit data network port
Other functions Time Division multiplexing, frequency division multiplexing, beam forming, MIMO
