H3C SFP-XG-LX-SM1310-D 10GBase-LR SFP+ Optical Transceiver Module

1. Product Overview

The H3C SFP-XG-LX-SM1310-D is a high-performance, hot-pluggable SFP+ optical transceiver designed for 10 Gigabit Ethernet applications. This H3C compatible module operates at a wavelength of 1310nm and is engineered for long-reach transmission up to 10 kilometers over single-mode fiber (SMF). It is a reliable and cost-effective solution for enterprise networks, data centers, and service provider infrastructures requiring high bandwidth and extended reach. The SFP-XG-LX-SM1310-D is fully compliant with the SFP+ MSA and IEEE 802.3ae standards, ensuring seamless interoperability with a wide range of H3C networking equipment.

2. Key Characteristics

• Supports data rates of 10.3125 Gbps (10GBASE-R)
• 1310nm DFB laser and PIN photo-detector
• Maximum link length of 10 km over standard single-mode fiber (SMF)
• Duplex LC optical connector interface
• Low power consumption, typically less than 1.5W
• Hot-pluggable SFP+ form factor
• Digital Diagnostic Monitoring (DDM) functionality via I2C interface
• Designed for use in H3C S7500E and S7500X series switches
• Operating case temperature: 0°C to 70°C (32°F to 158°F)

3. Technology & Standards

The SFP-XG-LX-SM1310-D module leverages advanced 1310nm Distributed Feedback (DFB) laser technology to achieve high-speed, long-distance data transmission. It is designed to meet stringent industry standards, ensuring reliability and compatibility.

• Compliant Standards: IEEE 802.3ae 10GBASE-LR, SFF-8472 (DDM/DOM), SFF-8431, SFF-8432
• Protocols: 10 Gigabit Ethernet
• Data Encoding: 64B/66B

4. Working Principle

The transceiver converts electrical signals from the host switch into optical signals using an integrated 1310nm DFB laser. These light pulses are transmitted through a single-mode optical fiber to a receiving transceiver. The receiver side of the module uses a PIN photodiode to convert the incoming optical signals back into electrical signals for the switch to process. The integrated Digital Diagnostic Monitoring (DDM) circuit provides real-time access to operational parameters such as optical output power, received power, laser bias current, and transceiver temperature, enabling proactive network management.

5. Application & Usage

The H3C SFP-XG-LX-SM1310-D is ideal for a variety of applications that require reliable 10G connectivity over medium to long distances.

• Data Center Interconnects: Connecting switches across different rooms or buildings.
• Enterprise Backbone Networks: Aggregating traffic between wiring closets and the main network core.
• Service Provider Access & Metro Networks: Providing high-bandwidth links for network aggregation.
• Storage Area Networks (SAN): Supporting high-speed storage protocols like Fibre Channel over Ethernet (FCoE).
• It is commonly deployed in compatible H3C switches such as the S7500E and S7500X series.

6. Specifications & Selection Guide

7. Advantages & Selling Points

• Guaranteed Compatibility: As a genuine H3C part, the SFP-XG-LX-SM1310-D is tested and certified to work flawlessly with H3C switches, avoiding compatibility issues common with third-party modules.
• Superior Quality & Reliability: Manufactured to high-quality standards, ensuring stable performance and a longer operational lifespan, which reduces total cost of ownership.
• Comprehensive Monitoring: DDM/DOM support allows for real-time network management and proactive fault detection, minimizing downtime.
• Cost-Effective Long-Reach Solution: Provides an optimal balance of performance and cost for 10G deployments requiring distances up to 10km.

8. Service & Support

We stand behind the quality of our products. This H3C module comes with a comprehensive warranty. Our company boasts over a decade of experience in the network hardware industry, supported by a large warehouse and a strong technical team. We offer competitive pricing, reliable supply with millions in inventory, and robust customer support.

• Warranty: Standard manufacturer warranty.
• Delivery: Rapid shipping options available from our extensive stock.
• Technical Support: 24/7 customer consultation and technical support to assist with integration and troubleshooting.

9. Frequently Asked Questions (FAQ)

Q1: Is this SFP+ module compatible with my H3C S7500X switch?
A1: Yes, the SFP-XG-LX-SM1310-D is designed to be fully compatible with H3C S7500X and S7500E series switches, as listed in the official documentation.

Q2: What is the difference between LX and SR transceivers?
A2: LX modules (like this 1310nm variant) are for long-reach transmission over single-mode fiber (up to 10km). SR modules (850nm) are for short-reach over multi-mode fiber (typically up to 300m).

Q3: Does this module support DDM/DOM?
A3: Yes, the SFP-XG-LX-SM1310-D supports Digital Diagnostic Monitoring, allowing you to monitor parameters like temperature, voltage, and optical power.

Q4: What type of fiber cable should I use with this transceiver?
A4: You must use a 9/125 µm single-mode duplex LC fiber patch cable for optimal performance over the advertised distance.
