Sodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment Systems
Sodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment Systems
Sodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment Systems
Sodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment Systems
Sodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment Systems
Sodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment Systems
Specifications
Packaging Details :
Woven fabric packaging
Supply Ability :
9999999㎡/MONTH
Brand Name :
YPEP
Swelling Performance :
High Expansion
Place of Origin :
China
Application :
Artificial Lake Water Reservoir
Delivery Time :
5 days
Material :
Natural Sodium Bentonite
Payment Terms :
T/T
Color :
Grey
Structure :
Geotextile Composite
Product Name :
Bentonite Waterproof Liner
Mass :
≥4800 g m2
Installation :
Easy Laying System
MOQ :
1000pcs
Description
Product Description

This bentonite waterproof liner is designed for water containment and artificial lake construction projects. It uses natural sodium bentonite as the core sealing material, which expands upon hydration to form a dense impermeable layer.

The liner is encapsulated between geotextile layers that provide mechanical strength and ensure even distribution of the bentonite. This structure enhances durability while maintaining excellent flexibility.

It is widely used in artificial lakes, ponds, reservoirs, and landscape water features where reliable waterproofing is essential. The material ensures minimal leakage while supporting long term water retention.

Unlike traditional waterproofing systems, this liner offers a self sealing function that automatically repairs minor punctures or damage when exposed to water.

Technical Data
Category Parameter Value
Product Type GCL
Material Bentonite Sodium
Physical Mass per Unit ≥4800 g m2
Mechanical Tensile Strength ≥600 N 100mm
Mechanical Peel Strength ≥40 N 100mm
Hydraulic Permeability ≤5.0*10⁻¹¹ m s
Chemical Swell Index ≥24
Chemical Fluid Loss ≤18
Structure Nonwoven Layer 200 g m2
Structure Woven Layer 110 g m2
Sodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment SystemsSodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment SystemsSodium Bentonite GCL Liner for Artificial Lake Waterproofing and Water Containment Systems
Why Choose Us
  • Strong waterproof performance for water systems
  • Natural eco friendly material
  • Easy installation with reduced labor cost
  • Long service life in outdoor environments
  • Custom specifications available
FAQ

Q: Can it be used in artificial lakes
A: Yes it is widely used in water landscape projects.

Q: Is it environmentally safe
A: Yes it is made from natural bentonite.
