Specifications
Place of Origin :
Guangdong, China
Brand Name :
Makinopc
Detection Poles :
ZPS024H-S: S pole; ZPS024H-N: N pole
Response time :
5μ sec
weight (kg) :
0.5
Machine Type :
Punching Machine, Milling Machine, lathe machine, Grinding Machine
Magnetic detection direction :
Forward
Current consumption :
15mA MAX
Protection class :
IP67
Price :
$5.75-6.58 / piece
MOQ :
1 piece
Supply Voltage :
DC5~24V
Indicator light :
Red color
Output current :
12mA MAX
Shell material :
Glass fiber reinforced resin: black
Magnetic sensitivity :
2.5~3.5mT
warranty :
1 Year
Description
Products Description
Magnetic sensor is a device for detecting and sensing magnetic field, which can be converted into electrical signal output. It is widely used in many fields, such as industrial automation, aerospace, medical equipment and so on.

Key Features

●Magnetic proximity sensors are sensors that operate ON and OFF according to changes in the strength of the magnetic field. ●The operating principle is the Hall principle, which detects the magnetic field according to its polarity, and the standard detection pole is the S pole. ●Because of the short response time (5μsec or less), it can also be used for tachometers and speedometers. ●Compared with general proximity sensors, it is characterized by high sensitivity, large detection distance, and small size. ●Can perform both home position and over-travel detection of servo mechanisms with only one dual sensor. ●Strong resistance to electromagnetic interference and high reliability.
Product Paramenters
Supply Voltage
DC5～24V
Detection Poles
ZPS024H-S: S pole
ZPS024H-N: N pole
Magnetic sensitivity
ZPS024H-S：0.8±0.2mT
Magnetic detection direction
ZPS024H-N: 0.9±0.2mT
Output mode
Forward
Output current
NPN normally open (ON when close)
Current consumption
12mA MAX
Response time
15mA MAX
Withstanding Voltage
5μ sec
Insulation resistance
AC1000V
(1 minute, between the whole charging part and the case)
DC250V
Operating Ambient Temperature
(20MΩ or more, between the whole charging part and the case)
Humidity
-20℃～+85℃ (no condensation)
Wire Specification
20～95%RH
φ2.8×1m
S pole: Gray
Shell material
N-pole: Black
Installation
Glass fiber reinforced resin: black
M9 nut Tightening torque 0.5N-m
Mounting aperture processing size
It is recommended to prevent loosening by using an adhesive or the like.
Indicator light
φ9 +0.5 / 0
Protection Class
Red color
Protection class
IP67
※Output conversion and current increase can be realized by wire attachment.
Details Images
Highly Sensitive Fast Magnetic Proximity Sensors for Motor Overload protection and Torque Detection ZPS024H
Highly Sensitive Fast Magnetic Proximity Sensors for Motor Overload protection and Torque Detection ZPS024H
Highly Sensitive Fast Magnetic Proximity Sensors for Motor Overload protection and Torque Detection ZPS024H
※Output conversion and current increase can be realized by wire attachment.
