ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection
ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection
ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection
ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection
Specifications
Brand Name :
IMission
Model Number :
ODM and OEM
Certification :
ISO9001
Place of Origin :
China
MOQ :
I PC
Price :
0.1~5USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
10000pcs per month
Delivery Time :
7~35 working days
Packaging Details :
Bubble and Carton or Customization
Material :
Brass
Weight :
0.1-10kg
Key Word :
CNC Milling Parts
Shipping Method :
Express, Air, Sea, Etc.
Feature :
Durable And High Precision
Processing :
CNC, Turning, Milling, Auto Lathe, Grinding, Stamping, Laser Cutting, Welding, 3D printing, Die Casting, Injection,etc.
Surface Finishing :
Polishing, Grinding, Anodize, Oxide, Laser, Engrave, Painting, Powder Coating, Hardness, etc.
Material Available :
Aluminum, Copper (Brass), Stainless Steel, Steel, Acetal, ABS, PVDF, PVC, Titanium,Etc.
Highlight :
ISO9001 Certified CNC Milling Parts，100% Inspection CNC Machined Parts，3D Printing Precision Milled Components
Description
ISO9001 Certified Precision CNC Milling Parts with Secondary Operations
CNC Milling Parts Specifications
Product Name CNC Milling Parts
Material Available Brass
Processing CNC Milling
Tolerance ±0.002~0.005mm
Drawing Accepted IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad, or Samples
Inspection CMM, Projector, Height Gauge, etc.
Lead Time 7~35 working days
Quality Assurance ISO9001:2015, SGS, RoHs
Payment Term MoneyGram, Western Union, T/T, D/P, D/A, L/C
Price According to your drawing or requirements
Engineer Support Available for engineering assistance and drawings design
Packaging and Delivery
Packaging Bubble and Carton or Customization
Port Shenzhen
ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection
CNC Milling Parts Key Features

CNC milling parts feature high precision and excellent surface finish. They can meet tight tolerance requirements and realize complex structural shapes. With stable quality and customizable design, they are suitable for various materials and widely used in industrial production.

Secondary Operations & Finishing
Value-Added Services
Operation Equipment/Process Capability Typical Tolerances
CNC Turning Live tooling on mills, separate lathes Turning features on milled parts ±0.01mm
Grinding Surface, cylindrical, jig grinders Precision flatness, parallelism, size ±0.002mm
EDM Wire and sinker EDM Complex geometries, hard materials ±0.005mm
Heat Treatment Vacuum furnaces, atmosphere controlled Hardening, tempering, stress relief Material dependent
Welding TIG, laser, electron beam Component assembly, repair ±0.05mm after weld
Assembly Press fits, adhesive, fastening Multi-component assemblies As per drawing
Surface Finishing Options
Finish Type Process Method Surface Ra (μm) Characteristics & Applications
As-Machined Standard CNC milling 0.8-3.2 Cost-effective, visible tool marks, general applications
Bead Blasting Glass bead, aluminum oxide 0.8-1.6 Matte finish, uniform appearance, stress relief
Polishing Mechanical, chemical, electro 0.025-0.4 Reflective, smooth, food, medical, optical
Anodizing Type I-III, hardcoat (Al) Base material dependent Decorative, corrosion resistant, wear resistant
Plating Nickel, chrome, zinc, tin Varies Corrosion protection, appearance, solderability
Powder Coating Electrostatic application N/A (coating) Durable, color options, corrosion protection
Passivation Nitric or citric acid (SS) Base material finish Corrosion resistance restoration
Laser Marking Fiber, YAG lasers N/A (marking) Permanent identification, serialization, logos
Tumbling/Vibratory Media finishing 0.4-1.6 Deburring, edge breaking, surface smoothing
Quality Assurance & Inspection
Inspection Equipment & Capabilities
  • CMM (Coordinate Measuring Machines): 3D measurement with 0.001mm accuracy, temperature controlled
  • Optical Comparators/Vision Systems: Non-contact measurement, 2D profile verification
  • Surface Roughness Testers: Contact and non-contact Ra, Rz, Rq measurements
  • Roundness/Form Testers: Cylindricity, concentricity, flatness verification
  • Hardness Testers: Rockwell, Brinell, Vickers, micro-hardness
  • Portable Arms: Articulated arms with laser scanner for large parts
  • Digital Height Gauges: Precision height measurement with 0.001mm resolution
  • Gauge Blocks & Calibrated Instruments: Full set to ISO 3650 standards
  • Force/Torque Measurement: For assembly validation, spring constant verification
Quality Management System
  • ISO 9001:2015 Certified: Full quality management system implementation
  • First Article Inspection: AS9102, PPAP, or custom FAIR documentation
  • Statistical Process Control: Real-time monitoring of critical characteristics
  • Material Certification: Mill test reports, material traceability to heat/lot
  • Calibration Program: All inspection equipment calibrated to NIST-traceable standards
  • Document Control: Revision-controlled drawings, specifications, procedures
  • Non-Conformance System: Documented containment, root cause analysis, corrective action
ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection ISO9001 Certified Precision CNC Milling Parts with ±0.002~0.005mm Tolerance and 100% Inspection

Target Industries & Applications

A. Aerospace & Defense

Components: Structural frames, brackets, housings, turbine components, fittings

Materials: Aluminum (2024, 7075), titanium, Inconel, high-strength steels

Standards: AS9100, NADCAP (machining), MIL specifications, customer-specific

Critical Requirements: Fatigue resistance, weight optimization, documentation, traceability

B. Medical & Life Sciences

Components: Surgical instruments, implantable devices, diagnostic equipment, prosthetics

Materials: 316L stainless, titanium (Grade 5, 23), PEEK, cobalt-chrome

Requirements: Biocompatibility, cleanroom manufacturing, sterilization compatibility

Regulations: FDA compliance, ISO 13485, USP Class VI testing where applicable

C. Automotive & Motorsports

Components: Engine parts, transmission housings, suspension components, brackets

Materials: Aluminum, various steels, brass, magnesium (racing)

Production Volumes: Prototype to high-volume (10,000+ parts)

Special Capabilities: JIT delivery, kanban systems, production line support

D. Electronics & Semiconductor

Components: Enclosures, heat sinks, wafer handling, test fixtures, connector bodies

Materials: Aluminum, copper, engineering plastics, composites

Precision Requirements: Often ±0.005mm or better, micron-level flatness

Cleanliness: ESD-safe materials, particulate control, specialized cleaning

E. Industrial Machinery & Automation

Components: Machine frames, brackets, guides, robotic components, fixture

Materials: Carbon steel, aluminum, stainless, cast iron

Requirements: Wear resistance, dimensional stability, rigidity

Capabilities: Large part machining, weldment preparation, assembly interfaces

Packaging, Shipping & Logistics
Packaging Solutions
  • Standard Packaging: Poly bags with desiccant in partitioned cartons
  • ESD-Sensitive: Antistatic bags, conductive foam, static-dissipative containers
  • Cleanroom Packaging: Double-bagged, cleanroom compatible materials
  • VCI Protection: Volatile corrosion inhibitor papers/films for ferrous metals
  • Custom Fixturing: CNC-machured foam inserts, custom racks, reusable containers
  • International Shipping: Export-rated crates, climate-controlled options available
Logistics & Supply Chain
  • Global Shipping: Relationships with major carriers (DHL, FedEx, UPS)
  • Export Documentation: Commercial invoice, packing list, certificate of origin
  • Compliance Documentation: Material certifications, RoHS/REACH declarations
  • Inventory Management: Consignment stock, bonded warehousing, kanban systems
  • Just-In-Time Delivery: Scheduled deliveries aligned with production schedules
