Specifications
Brand Name :
IMission
Model Number :
ODM and OEM
Certification :
ISO9001
Place of Origin :
China
MOQ :
I PC
Price :
0.1~5USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
10000pcs per month
Delivery Time :
7~35 working days
Packaging Details :
Bubble and Carton or Customization
Material :
Aluminum
Weight :
0.1-10kg
Key Word :
CNC Milling Parts
Shipping Method :
Express, Air, Sea, Etc.
Feature :
Durable And High Precision
Processing :
CNC, Turning, Milling, Auto Lathe, Grinding, Stamping, Laser Cutting, Welding, 3D printing, Die Casting, Injection,etc.
Surface Finishing :
Polishing, Grinding, Anodize, Oxide, Laser, Engrave, Painting, Powder Coating, Hardness, etc.
Material Available :
Aluminum, Copper (Brass), Stainless Steel, Steel, Acetal, ABS, PVDF, PVC, Titanium,Etc.
Highlight :
ISO9001 Certified CNC Milling Parts，100% Inspection CNC Machined Parts，3D Printing Precision Milled Components
Description
CNC Milling with Anodizing and Precision Tolerance Milling
CNC Milling Parts Specifications
Product Name Precision CNC Milling Parts
Material Available Aluminum
Processing CNC
Surface Finish Black Oxidation
Tolerance ±0.002~0.005mm
Drawing Accepted IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad, or Samples
Inspection CMM, Projector, Height Gauge, etc.
Lead Time 7~35 working days
Quality Assurance ISO9001:2015, SGS, RoHs
Payment Term MoneyGram, Western Union, T/T, D/P, D/A, L/C
Price According to your drawing or requirements
Engineer Support Available for engineering assistance and drawings design
Packaging and Delivery
Packaging Bubble and Carton or Customization
Port Shenzhen
ISO9001 Certified CNC Milling Parts with Anodizing and ±0.002~0.005mm Tolerance
CNC Milling Parts Features
Exceptional Precision & Tolerance Control

Achieve tight dimensional tolerances down to ±0.005mm with consistent geometries across batch production

Versatile Material Compatibility

Process aluminum alloys, stainless steel, titanium, brass, engineering plastics and composite materials

Complex Geometry Machining Capability

Create intricate shapes including 3D contours, deep pockets, internal threads, and custom cavities

Milling Processes & Special Operations
Core Milling Operations
  • Face Milling: Large surface area finishing, squaring operations
  • Peripheral Milling: Slotting, profiling, contour machining
  • Pocket Milling: Shallow and deep pocketing, cavity creation
  • Contour Milling: 2D and 3D surface profiling
  • Drilling/Tapping: Precision hole making, thread creation
  • Boring: High-precision hole sizing and finishing
  • Thread Milling: Internal and external thread creation
Advanced Machining Techniques
Technique Description Applications Benefits
High-Speed Machining High spindle speeds with reduced chip loads Aluminum, graphite, plastics Reduced cycle times, improved surface finish
Hard Milling Machining materials >45 HRC directly Tool steels, hardened steels Eliminates EDM, better surface integrity
Trochoidal Milling Constant engagement circular tool paths Deep slots, difficult materials Reduced tool wear, higher material removal
Micro-Milling Small tools (<1mm diameter) Medical devices, micro-optics, electronics Precision small features, fine details
5-Axis Simultaneous Continuous tool orientation control Turbine blades, impellers, complex geometries Single setup completion, complex contours
Tooling & Cutting Technology

Tool Materials: Carbide (various grades), CBN, PCD, diamond-coated, HSS

Tool Holding Systems: HSK, BT, CAT with hydraulic, thermal, or mechanical clamping

Cutting Tool Types: End mills (flat, ball, corner radius), face mills, slot cutters, drills, taps

Coolant Systems: High-pressure through-spindle (70-200 bar), minimum quantity lubrication, cryogenic options

Tool Management: Presetters, in-machine probing, automatic tool changers (30-200+ tools)

Secondary Operations & Finishing
Value-Added Services
Operation Equipment/Process Capability Typical Tolerances
CNC Turning Live tooling on mills, separate lathes Turning features on milled parts ±0.01mm
Grinding Surface, cylindrical, jig grinders Precision flatness, parallelism, size ±0.002mm
EDM Wire and sinker EDM Complex geometries, hard materials ±0.005mm
Heat Treatment Vacuum furnaces, atmosphere controlled Hardening, tempering, stress relief Material dependent
Welding TIG, laser, electron beam Component assembly, repair ±0.05mm after weld
Assembly Press fits, adhesive, fastening Multi-component assemblies As per drawing
Surface Finishing Options
Finish Type Process Method Surface Ra (μm) Characteristics & Applications
As-Machined Standard CNC milling 0.8-3.2 Cost-effective, visible tool marks, general applications
Bead Blasting Glass bead, aluminum oxide 0.8-1.6 Matte finish, uniform appearance, stress relief
Polishing Mechanical, chemical, electro 0.025-0.4 Reflective, smooth, food, medical, optical
Anodizing Type I-III, hardcoat (Al) Base material dependent Decorative, corrosion resistant, wear resistant
Plating Nickel, chrome, zinc, tin Varies Corrosion protection, appearance, solderability
Powder Coating Electrostatic application N/A (coating) Durable, color options, corrosion protection
Passivation Nitric or citric acid (SS) Base material finish Corrosion resistance restoration
Laser Marking Fiber, YAG lasers N/A (marking) Permanent identification, serialization, logos
Tumbling/Vibratory Media finishing 0.4-1.6 Deburring, edge breaking, surface smoothing
ISO9001 Certified CNC Milling Parts with Anodizing and ±0.002~0.005mm Tolerance ISO9001 Certified CNC Milling Parts with Anodizing and ±0.002~0.005mm Tolerance

Target Industries & Applications

A. Aerospace & Defense

Components: Structural frames, brackets, housings, turbine components, fittings

Materials: Aluminum (2024, 7075), titanium, Inconel, high-strength steels

Standards: AS9100, NADCAP (machining), MIL specifications, customer-specific

Critical Requirements: Fatigue resistance, weight optimization, documentation, traceability

B. Medical & Life Sciences

Components: Surgical instruments, implantable devices, diagnostic equipment, prosthetics

Materials: 316L stainless, titanium (Grade 5, 23), PEEK, cobalt-chrome

Requirements: Biocompatibility, cleanroom manufacturing, sterilization compatibility

Regulations: FDA compliance, ISO 13485, USP Class VI testing where applicable

C. Automotive & Motorsports

Components: Engine parts, transmission housings, suspension components, brackets

Materials: Aluminum, various steels, brass, magnesium (racing)

Production Volumes: Prototype to high-volume (10,000+ parts)

Special Capabilities: JIT delivery, kanban systems, production line support

D. Electronics & Semiconductor

Components: Enclosures, heat sinks, wafer handling, test fixtures, connector bodies

Materials: Aluminum, copper, engineering plastics, composites

Precision Requirements: Often ±0.005mm or better, micron-level flatness

Cleanliness: ESD-safe materials, particulate control, specialized cleaning

E. Industrial Machinery & Automation

Components: Machine frames, brackets, guides, robotic components, fixture

Materials: Carbon steel, aluminum, stainless, cast iron

Requirements: Wear resistance, dimensional stability, rigidity

Capabilities: Large part machining, weldment preparation, assembly interfaces
